MAXIM INTEGRATED / ANALOG DEVICES MAX489EPD RS-485 Transceiver

The MAX489EPD+ is a low power, slew rate limited RS-485/RS-422 transceiver housed in a 14-pin NSOIC package. It includes one driver and one receiver, with a driver designed to minimize electromagnetic interference (EMI) and signal reflections caused by improperly terminated cables. This allows error-free data transmission at speeds up to 250 Kbps. The transceiver features short circuit current limiting, thermal shutdown protection, and fail-safe circuitry that ensures a high-level output when the receiver input is open. Operating over a supply voltage range of 4.75V to 5.25V and an extended temperature range from -40°C to 85°C, it is suitable for full duplex communication, industrial networks, and low-power applications. Additional features include receiver and driver enable functions, a quiescent current of 120µA, and support for up to 32 transceivers on a bus. It is ideal for industrial control systems, LANs, level translation, and EMI-sensitive environments.

View MAX489EPDDatasheet [pdf]

Buy the Buy Maxim RS-485 Transceiver Part Number MAX489EPD Online

Purchase the Maxim MAX489EPD low-power RS-485/RS-422 transceiver online today. Designed for robust industrial communications, it features EMI minimization, thermal shutdown, and fail-safe operation, ensuring error-free data transfer up to 250 Kbps. Operating from 4.75V to 5.25V with a temperature range from -40°C to 85°C, this device supports up to 32 transceivers on a bus. Perfect for industrial control, LANs, and low-power environments, order now to enhance your network's reliability and performance.

Order your Maxim MAX489EPD high-speed RS-485/RS-422 transceiver today and ensure reliable, low-noise industrial communication with minimal EMI and robust protections.
