MAXIM INTEGRATED / ANALOG DEVICES MAX5035BUSAT Step-Down DC-DC Converter
The MAX5035BUSA+T from Maxim Integrated Products is a high-efficiency, step-down DC-DC converter capable of delivering up to 1A of current with an input voltage range from 7.5V to 76V. Packaged in an 8-pin NSOIC, this device features internal frequency compensation, a fixed switching frequency of 125kHz, and operates with a quiescent current of only 270µA at no load. It utilizes an internal low-resistance high-voltage DMOS transistor to ensure high efficiency and reduce system costs. The converter automatically switches to pulse skipping mode at light loads to maintain high efficiency and low quiescent current. Protective features include undervoltage lockout, cycle-by-cycle current limiting, hiccup mode short-circuit protection, thermal shutdown, and an internal 0.4Ω high-side DMOS FET. Typical applications include automotive, consumer electronics, industrial systems, and distributed power supplies.
MAXIM INTEGRATED / ANALOG DEVICES MAX5035BUSAT Step-Down DC-DC Converter Specifications:
- Input Voltage Range: 7.5V to 76V
- Output Current: Up to 1A
- Switching Frequency: Fixed 125kHz
- Quiescent Current: 270µA at no load
- Protection: Undervoltage lockout, cycle-by-cycle current limit, hiccup mode short circuit protection, thermal shutdown
- Output Voltage: Fixed (3.3V, 5V, 12V) and adjustable (1.25V to 13.2V)
- Package: 8-pin NSOIC
- Operating Temperature Range: -40°C to +125°C
- Internal High-Side DMOS Transistor Resistance: 0.4Ω
Buy the Maxim Series MAX5035 Step-Down DC-DC Converter: MAX5035BUSAT
Purchase the Maxim Series MAX5035 BUSAT online today to ensure your project benefits from high efficiency, robust protection features, and wide input voltage compatibility. This 1A step-down converter is ideal for automotive, industrial, and consumer electronics, offering excellent performance from 7.5V to 76V. With internal compensation, low quiescent current of only 270µA, and advanced protections including thermal shutdown and hiccup mode, it provides reliable power regulation for demanding applications. Order now for fast delivery and quality assurance.
Buy Maxim Series MAX5035 BUSAT now and experience unmatched reliability and performance in industrial and automotive power applications.
