MAXIM INTEGRATED / ANALOG DEVICES MAX5389LAUD Digital Potentiometer
The MAX5389LAUD is a versatile component designed for a variety of applications including adjustable voltage reference and linear regulation, audio mixing, low-drift programmable filters and amplifiers, and low-voltage battery-powered systems. It also serves as a mechanical potentiometer replacement and supports programmable delays and time constants for precise control in electronic circuits.
MAXIM INTEGRATED / ANALOG DEVICES MAX5389LAUD Digital Potentiometer Specifications:
- Resistance Values: 10kQ, 50kQ, 100kQ end-to-end resistance
- Operating voltage: +2.6V to +5.5V
- Wiper resistance: 150-200Ω depending on supply voltage
- Resolution: 256 taps
- End-to-end resistor tempco: 35 ppm/°C
- Operating temperature: -40°C to +125°C
- Package: 14-pin TSSOP
- Power dissipation: 796.8mW at 70°C (derate 10mW/°C above 70°C)
- Input leakage current: ±1pA
- Voltage range: Vpp = 2.6V to 5.5V
- Differential Nonlinearity: ±0.5LSB
- Integral Nonlinearity: ±0.5LSB
- Total Harmonic Distortion: 0.015%
Buy the Buy MAXIM Integrated MAX5389LAUD Part Number 50kQ Online
Purchase the MAX5389LAUD digital potentiometer online today to enhance your electronic projects with precise 256-tap control, low-voltage operation from 2.6V to 5.5V, and a wide temperature range of -40°C to +125°C. Ideal for filters, audio mixing, battery-powered systems, and as a mechanical potentiometer replacement, it offers high linearity, low resistance variation, and robust performance in compact TSSOP packaging. Get reliable, easy-to-integrate digital control for your designs now.
Buy MAXIM MAX5389LAUD now and experience unmatched reliability and performance in low-voltage digital potentiometers with precise tap control.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX5389LAUD?
You can click on the BUY or RFQ button to purchase MAX5389LAUD from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX5389LAUD?
You can download the MAX5389LAUD datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX5389LAUD?
MAXIM INTEGRATED / ANALOG DEVICES
