MAXIM INTEGRATED / ANALOG DEVICES MAX9691EUA High-Speed Comparator
The MAX9691EUA is an ultra-fast ECL comparator featuring differential inputs, complementary outputs, and built-in latch enable functionality. Capable of operation at frequencies exceeding 600 MHz, it offers a propagation delay of 1.2 ns with 100 ps skew, ideal for high-speed line reception, peak detection, and threshold applications. Designed in compact SO, QSOP, and uMAX packages, it operates on +5V and -5.2V supplies, with input voltage range of -2.5V to +3.0V, ensuring excellent DC matching and low noise susceptibility for demanding industrial signal processing.
MAXIM INTEGRATED / ANALOG DEVICES MAX9691EUA High-Speed Comparator Specifications:
- Propagation Delay: 1.2 ns
- Propagation Delay Skew: 100 ps
- Dispersion: 150 ps
- Latch Setup Time: 0.5 ns
- Output Current Capability: 50 mA
- Supply Voltage: +5V, -5.2V
- Input Voltage Range: -2.5V to +3.0V
- Package Options: SO, QSOP, uMAX
- Operating Temperature Range: -40°C to +85°C
- Differential Input Resistance: 60 kΩ
- Input Offset Voltage: 11.5 mV (max)
- Input Bias Current: 30 nA (max)
- Open-Loop Gain: 70 dB
- Propagation Delay: 12-18 ns (max)
- Rise/Fall Time: 500 ps
- Latch Enable Pulse Width: 1.0 ns
Buy the Maxim MAX9691EUA – Reliable High-Speed Comparator for Industrial Applications
Purchase the Maxim MAX9691EUA today for superior high-speed signal detection and threshold applications. Featuring ultra-fast 1.2 ns propagation delay, differential inputs, and latch enable, it is perfect for demanding industrial environments. Compact in SO, QSOP, and uMAX packages, it operates at ±5V with excellent DC matching. Enhance your circuits with this reliable comparator designed for frequencies exceeding 600 MHz, ensuring precise and fast response in high-frequency line receivers, peak detectors, and trigger circuits.
Buy Maxim MAX9691EUA now and experience unmatched reliability and performance in high-speed industrial signal processing tasks.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX9691EUA?
You can click on the BUY or RFQ button to purchase MAX9691EUA from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX9691EUA?
You can download the MAX9691EUA datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX9691EUA?
MAXIM INTEGRATED / ANALOG DEVICES
