MEAN WELL DDR120B24 Industrial DC-DC Converter
The DDR-120B-24 is a 120W DIN Rail DC-DC converter designed for industrial and railway control applications. It features wide input voltage ranges of 16.8~33.6V, with adjustable 24V output, high efficiency, and full protective functions including over-voltage, short circuit, reverse polarity, and under-voltage lockout. Suitable for environments with -40°C to +70°C operating temperature, it ensures reliable operation in harsh conditions. Its compact 32mm width facilitates easy DIN rail installation, meeting demanding standards such as EN50155 and EN45545-2 for fire safety and electromagnetic compatibility.
MEAN WELL DDR120B24 Industrial DC-DC Converter Specifications:
- Power: 120W
- Input Voltage Range: 16.8~33.6V
- Output Voltage: 24V
- Rated Current: 5A
- Current Range: 0-5A
- Peak Power: 180W (3sec.)
- Ripple & Noise: 50mVp-p
- Voltage Adjustment Range: 24~28V
- Voltage Tolerance: ±1.0%
- Efficiency: 98.5%
- Operating Temperature: -40°C to +70°C
- Isolation Voltage: 4KVdc (input/output, relay contact)
- Protection: Over-voltage, short circuit, reverse polarity, under-voltage lockout
- Dimensions: 32 x 102 x 102 mm (W x H x D)
- Protection Class: IEC 61373 shock & vibration compliant
- Compliance Standards: EN50155, EN45545-2, UL508, IEC62368-1
- MTBF: 214,600 hours
Buy the Buy Mean Well DDR-120B-24 Part Number DDR120B24 Online
Secure your industrial control projects with the DDR-120B-24 series DC-DC converter from Mean Well. Featuring wide input voltage, adjustable 24V output, high efficiency of 98.5%, and extensive protection features, this compact DIN rail device is suitable for demanding environments. It ensures stable power supply for railway, factory automation, and communication systems, operating reliably from -40°C to +70°C. Quick online purchase guarantees a durable, standard-compliant power module that enhances system performance and safety across various applications.
Order your Mean Well DDR-120B-24 series 24V industrial DC-DC converter today and enhance your control systems with reliable, high-efficiency power solutions.
Frequently Asked Questions
Where can I buy MEAN WELL DDR120B24?
You can click on the BUY or RFQ button to purchase DDR120B24 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR120B24?
You can download the DDR120B24 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR120B24?
MEAN WELL
