MEAN WELL DDR15L5 Industrial DC-DC Converter
The DDR-15L-5 is a compact 15W DIN rail DC-DC converter designed for industrial automation, control, and communication systems. It features adjustable output voltage, ultra-wide input range of 18-75V, and operates across -40°C to +85°C. The module provides reinforced 4KVdc isolation, protections against short circuits, overloads, overvoltage, reverse polarity, and undervoltage. Its slim profile of 17.5mm width allows easy DIN rail mounting, making it ideal for factory automation, semiconductor equipment, and wireless networks. Reliable and certified to meet safety and EMC standards.
MEAN WELL DDR15L5 Industrial DC-DC Converter Specifications:
- Dimensions: 17.5mm width, 90mm height, 54.5mm depth
- Input Voltage: 18-75V DC (L-type) or 9-36V DC (G-type)
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V (adjustable +/-10%)
- Rated Power: 15W
- Ripple & Noise: 50-100mVp-p depending on model
- Input/Output Isolation: Reinforced 4KVdc
- Operating Temperature: -40°C to +85°C
- Protection: Short circuit, overload, overvoltage, reverse polarity, undervoltage lockout
- Efficiency: Up to 86%
- Voltage Adjustment Range: 30-36V for 3.3V output, 45-5V for 5V, 9-13.2V for 12V, 13.5-16.5V for 15V, 21.6-28V for 24V
- Vibration: IEC60068-2-6 compliant
- Humidity: 5-95% RH, non-condensing
- Safety Standards: IEC 62368-1, UL508, Safety and EMC compliant
Buy the FAL C€ DDR15L5 – Reliable Industrial Power Supply for Automation Applications
Purchase the FAL C€ DDR15L5 industrial DC-DC converter online today. This 15W module offers adjustable output, ultra-wide input voltage, and high temperature tolerance. Its compact design of 17.5mm width allows easy DIN rail mounting, suitable for automation, control, and communication systems. With comprehensive protections, reinforced 4KVdc isolation, efficiency up to 86%, and proven safety standards, it ensures reliable operation in demanding industrial environments. Ideal for seamless voltage regulation, system insulation, and voltage drop compensation across cables. Buy now to enhance your power management solutions.
Get FAL C€ DDR15L5 today—built for precision, durability, and versatile DIN rail installation in industrial environments.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15L5?
You can click on the BUY or RFQ button to purchase DDR15L5 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15L5?
You can download the DDR15L5 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15L5?
MEAN WELL
