MEAN WELL DDR30G15 Industrial DC-DC Converter
The DDR-30G-15 series is a 30W DIN Rail-mounted DC-DC converter designed for industrial automation, communication, and control applications. It features an ultra-slim 35mm width, ultra wide 4:1 input voltage range, and a broad operating temperature of -40°C to +85°C. The device offers adjustable output voltage (+10%), 4KV DC I/O isolation, and comprehensive protections including short circuit, overload, over-voltage, reverse polarity, and under-voltage lockout. Suitable for factory automation, security systems, wireless networks, and telecom installations, this converter ensures reliable power regulation with high efficiency and safety compliance.
MEAN WELL DDR30G15 Industrial DC-DC Converter Specifications:
- Input Voltage Range: 9-36V or 18-75V
- Output Power: 30W
- Output Voltage Options: 5V, 12V, 15V, 24V
- Rated Current: 6A for 5V, 2A for 12V, 2A for 15V, 1.25A for 24V
- Efficiency: up to 91%
- Ripple & Noise: Max. 75mVp-p
- Temperature Range: -40°C to +85°C
- Isolation Voltage: 4KV DC
- Protections: Short circuit, Overload, Over voltage, Reverse polarity, Under voltage lockout
- Dimensions: 35mm (W) x 54.5mm (H) x 90mm (D)
- DIN Rail Mount: TS-35/7.5 or 15
- Safety Standards: IEC 62968-1, UL508
- Vibration: 10-500Hz, 2G, 60 min per axis
- MTBF: 483,300 hours
- Connector: Terminal block with dedicated pin assignments
Buy the EAL DDR30G15 – Reliable Industrial Power Supply for Control and Communication Systems
Purchase the EAL DDR30G15 industrial DC-DC converter online to ensure reliable, efficient power regulation for automation, telecom, and industrial systems. Featuring an ultra-wide input range, adjustable output voltage (+10%), and high isolation, this device guarantees safe operation in harsh environments with a broad temperature range of -40°C to +85°C. It includes comprehensive protections such as short circuit, overload, over-voltage, reverse polarity, and under-voltage lockout, making it ideal for factory automation, wireless networks, security control, and communication systems. Enhance your systems with this durable, high-performance power solution, available now for fast online ordering.
Get EAL DDR30G15 today—built for industrial control, communication, and automation with high efficiency and robust protections.
Frequently Asked Questions
Where can I buy MEAN WELL DDR30G15?
You can click on the BUY or RFQ button to purchase DDR30G15 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR30G15?
You can download the DDR30G15 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR30G15?
MEAN WELL
