MEAN WELL DETN01L15 1W Isolated DC-DC Converter
The MEAN WELL DETN01L-15 series is a 1W isolated and unregulated DC-DC converter module with an SMD package. It boasts international standard pins, up to 83% efficiency, a wide working temperature range of -40°C to +90°C, 3KVDC isolation voltage, compliance with BS EN/EN55032 radiated Class B, short-circuit protection, and more. These modules accommodate different input voltages (5V/12V/24V ±10%) and various output voltages (±5V/±12V/±15V) for dual output, suitable for industrial control, telecommunication fields, and distributed power architectures.
MEAN WELL DETN01L15 1W Isolated DC-DC Converter Specifications:
- input_voltage_range: 4.5 ~ 5.5Vdc (L), 10.8 ~ 13.2Vdc (M), 21.6 ~ 26.4Vdc (N)
- surge_voltage: 9Vdc (5Vin models), 16Vdc (12Vin models), 30Vdc (24Vin models)
- filter: Internal capacitor
- protection: Fuse recommended (750mA for 5V, 300mA for 12V, 150mA for 24V)
- internal_power_dissipation: 500mW
- voltage_accuracy: ±2.0%
- rated_power: 1W
- ripple_noise: 75mVp-p
- line_regulation: ±1.2%
- load_regulation: ±8%
- switching_frequency: 100KHz
- short_circuit_protection: 0.5 second max (standard), Continuous (optional)
- cooling: Free-air convection
- working_temperature: -40 ~ +90°C (standard), -40 ~ +105°C (optional)
- case_temperature: +100°C max
- working_humidity: 20% ~ 90% RH non-condensing
- storage_temperature_humidity: -55 ~ +125°C, 10 ~ 95% RH non-condensing
- temp_coefficient: 0.03% /°C (0 ~ 85°C)
- soldering_temperature: 1.5mm from case for 1 ~ 10sec / 240°C max
- vibration: 10 ~ 500Hz, 2G 10min/1cycle
- safety_standards: UL62368-1, EAC TP TC 020/2011
- withstand_voltage: 3KVDC (I/P-O/P)
- isolation_resistance: 100M Ohms / 500VDC / 25°C / 70% RH
- isolation_capacitance: 80pF
- emc_emission: BS EN/EN55032
- mtbf: 880K hrs min. (MIL-HDBK-217F)
- dimensions: 15.24 x 10.9 x 7.1mm
- case_material: Non-Conductive black plastic (UL 94V-0 rated)
