MEAN WELL GSM18B09P1J Medical Power Adapter
The GSM18B series is a high-reliability, medical-grade 18W adaptor with a universal input ranging from 80VAC to 264VAC, suitable for medical devices like blood glucose meters, blood pressure monitors, and nebulizers. It features a 2-pin IEC320-C8 AC inlet, low leakage current (<50uA), high efficiency up to 88%, and low no-load power consumption (<0.1W). With safety approvals (2 x MOPP), fully enclosed flame-retardant plastic, optional lockable DC plug, and protections against short circuit, overload, and overvoltage, this adaptor ensures safe, energy-efficient operation for medical applications.
MEAN WELL GSM18B09P1J Medical Power Adapter Specifications:
- Input Voltage: 80VAC to 264VAC
- Output Power: 18W
- Output Voltage: 5V, 7.5V, 12V, 15V, 18V, 24V, 48V (various models)
- Rated Current: 3A for 5V, 2A for 7.5V, 2A for 12V, 1A for 15V, 0.75A for 18V, 0.375A for 24V, 0.2A for 48V
- Ripple & Noise: Max 60mVp-p (varies by model)
- Efficiency: Up to 88%
- Leakage Current: <50uA
- Dimensions: 79mm x 54mm x 33mm
- Protection: Short circuit, Overload, Overvoltage
- Temperature Range: -25°C to +60°C
- Certifications: UL60601-1, EN60601-1, TUV
- Environmental Conditions: Storage -40°C to +85°C, Humidity 10-95% RH
- MTBF: 796,700 hours
Buy the Reliable Medical Power Supply for Portable Devices
Purchase the GSM18B series medical power adaptor online today and enjoy reliable performance with high efficiency up to 88%. Designed specifically for medical devices such as blood glucose meters and nebulizers, this adaptor features low leakage current, comprehensive safety protections, and compliance with international standards. Its universal input range and optional locking DC plug make it versatile for various applications. Secure your medical device's power supply now and ensure safe, efficient, and compliant operation with this high-quality adaptor, backed by a three-year warranty.
Order your trusted GSM18B series medical adaptor today and ensure safe, energy-efficient operation for your portable healthcare equipment.
Frequently Asked Questions
Where can I buy MEAN WELL GSM18B09P1J?
You can click on the BUY or RFQ button to purchase GSM18B09P1J from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part GSM18B09P1J?
You can download the GSM18B09P1J datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of GSM18B09P1J?
MEAN WELL
