MEAN WELL MPM305ST Medical Power Supply
The MPM-30 series is a compact, high-reliability medical power supply offering 30W output power with excellent efficiency up to 91%. Designed to meet IEC/EN 60601-1 and ANSI/AAMI ES60601-1 standards, it features double insulation and ultra-low leakage current, making it suitable for BF applications such as portable medical devices, medical monitors, and examination instruments. With a small form factor of 69.5x39x24mm, it operates over a wide input range of 80-264VAC, ensuring stable performance in various medical environments, while providing protections against short circuits, overloads, and overvoltage conditions.
MEAN WELL MPM305ST Medical Power Supply Specifications:
- Power Output: 30W
- Input Voltage: 80-264VAC, 47-63Hz
- Output Voltage: 3.3V, 5V, 12V, 15V, 24V, 48V options
- Rated Current: 6A for 3.3V and 5V, up to 2A for 24V, 0.63A for 48V
- Peak Current: 7A, 6.9A, 2.98A, 2.34A, 1.5A, 0.73A respectively
- Efficiency: Up to 91%
- Dimensions: 69.5mm x 39mm x 24mm (PCB mounting), 91mm x 39mm x 28.5mm (screw terminal)
- Working Temperature: -40°C to +85°C
- Leakage Current: Less than 80μA at 264VAC
- Isolation: 2x MOPP, 4KVAC
- Protection: Short circuit, overload, overvoltage
- EMC Performance: Class B emission, industry standard immunity
- Vibration Resistance: 5G, 10-500Hz
- Altitude: Up to 5000 meters (PCB mounting), 3000 meters (screw terminal)
Buy the MedicalPower 30W Medical Power Supply – Reliable Medical Equipment Power Source for Industrial Applications
Purchase the MedicalPower MPM-30 medical power supply online to ensure reliable performance in critical healthcare applications. This 30W module offers high efficiency up to 91%, ultra-low leakage current, and meets strict medical safety standards such as IEC/EN 60601-1 and ANSI/AAMI ES60601-1. Its compact size of 69.5x39x24mm makes it ideal for portable and BF medical devices, providing protections against short circuits, overloads, and overvoltage. The unit operates over a wide input range of 80-264VAC and features a robust design for various demanding medical environments, ensuring dependable, long-lasting operation.
Get MedicalPower MPM-30 today—built for precision, efficiency, and long-lasting durability in medical environments.
Frequently Asked Questions
Where can I buy MEAN WELL MPM305ST?
You can click on the BUY or RFQ button to purchase MPM305ST from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part MPM305ST?
You can download the MPM305ST datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of MPM305ST?
MEAN WELL
