MEAN WELL IRM0233S Miniature Power Supply Module
IRM-02 series encapsulated power supplies are compact, reliable 2W modules designed for industrial and electronic applications. They feature universal AC input (85-305VAC), high efficiency up to 77%, and ultra-low no-load power consumption below 0.075W, meeting global energy regulations. The robust phenolic and silicone-potted cases ensure excellent heat dissipation, dust and moisture resistance, and anti-vibration capability up to 5G. With built-in EMI filtering, they comply with EN55022 Class B, offering protections against short circuit, overload, and overvoltage. Suitable for factory automation, handheld devices, and industrial electronics, they ensure safe, efficient operation.
MEAN WELL IRM0233S Miniature Power Supply Module Specifications:
- Input Voltage: 85-305VAC
- Output Voltage Options: 3.3V, 5V, 9V, 12V, 15V, 24V
- Rated Power: 2W
- Output Current: 83mA to 600mA depending on model
- Ripple & Noise: Max. 150mVp-p (varies by model)
- Voltage Tolerance: ±2.5% to ±25%
- Input Frequency Range: 47-63Hz
- Efficiency: Up to 77%
- No-load Power Consumption: <0.075W
- Isolation Voltage: 3KVAC (O/P to GND)
- Working Temp: -30°C to +85°C
- Protection Features: Short circuit, Overload, Overvoltage
- EMC Compliance: EN55022 Class B
- Vibration Resistance: Up to 5G
- Form Factor: PCB mounting and SMD styles
- Dimensions: 33.7mm x 22.2mm x 15mm (PCB); 33.7mm x 22.2mm x 4.6mm (SMD)
- Warranty: 3 years
Buy the Mean Well Series IRM-02 2W Power Supply Module: IRM0233S
Purchase the compact and high-efficiency IRM-02 power supply module online today. Perfect for industrial automation, electronic devices, and factory equipment, it offers universal input, low noise, and reliable protection features. Its robust design ensures long-term operation in challenging environments, with compliance to EMC standards and a 3-year warranty. Order now to enhance your electronic systems with this dependable, space-saving power solution, available with fast shipping and excellent customer support.
Order your Mean Well series IRM-02 power supply today and ensure dependable performance in your industrial and electronic projects.
Frequently Asked Questions
Where can I buy MEAN WELL IRM0233S?
You can click on the BUY or RFQ button to purchase IRM0233S from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part IRM0233S?
You can download the IRM0233S datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of IRM0233S?
MEAN WELL
