MEAN WELL XLG240LAB 240W LED Driver
The MEAN WELL XLG-240-L-AB series is a 240W LED AC/DC driver featuring constant power mode. It offers a wide input range (100~305VAC) and models with different rated currents. With high efficiency (up to 93.5%) and a fanless design, this series is suitable for both indoor and outdoor applications, including street lighting, floodlights, and horticulture lighting. It incorporates protection functions like OVP, SCP, and OCP, and meets international safety regulations like UL8/50 and ENEC EN61347.
MEAN WELL XLG240LAB 240W LED Driver Specifications:
- Model: XLG-240-L-AB
- Output Voltage: 12V
- Rated Current: 18A
- Ripple & Noise: 180mVp-p
- Voltage Tolerance: 8.4~ 12V
- Rated Power: 216W
- Line Regulation: ±3.0%
- Load Regulation: ±0.5%
- Setup, Rise Time: ±2%
- Efficiency: 92%
- Constant Current Region: 13.5 ~ 18V
- Frequency Range: 47 ~ 63Hz
- Input Voltage Range: 100 ~ 305VAC
- Input Current: 2.7A / 115VAC, 1.3A / 230VAC, 1.1A/277VAC
- Power Factor: 0.97/115VAC, 0.95/230VAC, 0.92/277VAC@full load
- Leakage Current: 0.75mA / 277VAC
- Working Temperature: -40 ~ +90℃
- Working Humidity: 20 ~ 95% RH non-condensing
- Storage Temperature & Humidity: -40 ~ +85℃, 10 ~ 95% RH
- Temperature Coefficient: 0.03%/℃
- Vibration: 10 ~ 500Hz, 5G 12min./1cycle
- MTBF: 830.77K hrs min.
- Dimension: 35.5mm (L*W*H)
- Packing: 1Kg;16pcs / 16Kg / 0.77CUFT
- Over Temperature Protection: Shut down output voltage, re-power on to recover
- Over Voltage Protection: 320 ~ 370VAC (Shut down output voltage)
- Surge Protection: 6K V/4K V (10K V/6K V)
- Isolation Resistance: 100M Ohms / 500VDC / 25℃
- Withstand Voltage: I/P-O/P:3.75KVAC, I/P-FG:2.0KVAC, O/P-FG:1.5KVAC
- Total Harmonic Distortion: <10%
- Hold Up Time: ≧
- Constant Power Mode: Full power output at 70~100%
- Protection Functions: OVP/SCP/OCP/O
- Life Time: >50,000 hrs
- Input Inrush Current: 500ms, 100ms/230VAC, 1200ms, 100ms/115VAC
- Dimming Function: 3-in-1 dimming function (O~10Vdc, 10V PWM signal and resistance dimming)
- Max Case Temperature: Tcase=+90℃
