MEAN WELL XLG25AB LED Driver
The XLG-25 series is a 25W AC/DC LED driver designed for flexible indoor and outdoor LED lighting applications. It features constant power mode output, high efficiency up to 88%, and wide operating temperature from -40°C to +85°C. Its robust IP67-rated metal housing protects against dust and water ingress, making it ideal for street, architectural, bay, and floodlighting. Equipped with dimming options including 0-10V, PWM, and resistance, it offers installation flexibility and reliable operation with a lifetime exceeding 50,000 hours and a 5-year warranty.
MEAN WELL XLG25AB LED Driver Specifications:
- Rated Power: 25W
- Input Voltage: 100~305VAC
- Rated Current: 700mA
- Constant Current Region: 22~54V
- Open Circuit Voltage (max.): 57V
- Output Current Adjustment Range: 0.25~1.05A
- Efficiency: up to 88%
- Total Harmonic Distortion: <20% at full load
- Power Factor: >0.9
- Dimming: 0-10V, PWM signal, Resistance (3 in 1 dimming)
- Operating Temperature: -40°C to +85°C
- Humidity Range: 20~95% RH non-condensing
- Ingress Protection: IP67
- Lifetime: >50,000 hours
- Protection: Over Power, Short Circuit, Over Temperature
- Dimensions: 105 x 63 x 30 mm
- Mounting: Metal housing with functional grounding
Buy the Mean Well XLG-25 U–Reliable LED Driver for Industrial Applications
Purchase the Mean Well XLG-25 LED driver online today to ensure your indoor and outdoor lighting systems are powered with high efficiency and durability. This 25W model features IP67 protection for water and dust resistance, making it suitable for street, architectural, and floodlighting. With multiple dimming options including 0-10V, PWM, and resistance, it offers flexible installation. Designed for long-term operation, it provides over 50,000 hours of reliable service, backed by a 5-year warranty. Get yours now for optimal lighting performance and peace of mind.
Buy Mean Well XLG-25 now and experience unmatched reliability and performance in your LED lighting projects.
Frequently Asked Questions
Where can I buy MEAN WELL XLG25AB?
You can click on the BUY or RFQ button to purchase XLG25AB from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part XLG25AB?
You can download the XLG25AB datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of XLG25AB?
MEAN WELL
