MOLEX 09507051 KK 3.96mm Crimp Terminal Housing
The MOLEX 09-50-7051 is a KK 3.96mm crimp terminal housing within the 2139 series, designed for robust wire-to-board connectivity. Constructed from natural nylon resin, this housing accommodates a maximum of 5 circuits and is suitable for power applications. It is RoHS compliant and features a receptacle gender. Compatible with various KK 396 headers and utilizes 2478 or 2578 crimp terminals for secure connections. Refer to the product specification PS-08-50-001 for detailed operating temperature range information.
MOLEX 09507051 KK 3.96mm Crimp Terminal Housing Specifications:
- overview: KK® Interconnect System
- description: KK 3.96mm Crimp Terminal Housing, 5 Circuits, Natural
- circuits_maximum: 5
- color: Natural
- flammability: 94V-2
- gender: Receptacle
- material: Nylon
- net_weight: 1.280 g
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 3.96mm
- operating_temperature_range: See Product Specification
- application: Power, Wire-to-Board
- series: 2139
- upc: 800753531512
- mates_with: KK 396 Headers: 41771, 41772, 41791, 41792, 42491, 42492, KK 396 Breakaway Headers: 41661, 41662, 41671, 41672
- use_with: 2478 Crimp Terminals for 18-24 AWG, 2578 Crimp Terminals for 22-26 AWG
- elv: Not Relevant
- rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Low-Halogen
