MOLEX 1051330021 Micro-USB B Receptacle
The MOLEX 105133-0021 is a Micro-USB B receptacle, ideal for applications requiring a compact and reliable USB connection. Its surface mount design simplifies integration into PCBs, while the vertical orientation optimizes space utilization. Constructed with copper alloy and gold-plated contacts, this receptacle ensures excellent signal integrity and durability. It is lead-free and compliant with RoHS standards, aligning with environmental regulations. This component is commonly used in consumer electronics, portable devices, and other applications demanding a robust USB interface.
MOLEX 1051330021 Micro-USB B Receptacle Specifications:
- overview: USB Products and Solutions
- status: Active
- description: Micro-USB B Receptacle with Flange, Vertical, Surface Mount, 7.80mm Height, 2.30mm Solder Tabs, Lead-Free
- agency_certification: UL E107635
- eu_elv: Not Relevant
- eu_rohs: Compliant
- china_rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Low-Halogen
- series: 105133 Series
- io_connectors: 105133
- wire_to_board: Signal contacts 1.0A, Power contacts 1.8A
- gender: Female
- keying: Yes
- lock: No
- material_metal: Copper Alloy
- material_plating_mating: Gold over Palladium Nickel
- material_plating_termination: Gold
- material_resin: Liquid Crystal Polymer
- circuits_loaded: 5
- circuits_maximum: 5
- color_resin: Black
- durability_mating_cycles: 10000
- flammability: 94V-0
- number_of_rows: 1
- orientation: Vertical
- pcb_retention: None
- packaging_type: Embossed Tape on Reel
- panel_mount: No
- pitch_mating_interface: 0.65mm
- pitch_termination_interface: 0.65mm
- polarized: Yes
- ports: 1
- surface_mount_compatible: No
- temperature_range_operating: -30° to +85°C
- waterproof_dustproof: No
- current_maximum_per_contact: 1.8A, 1.0A
- voltage_maximum: 30V AC (RMS)
- net_weight: 0.425/g
