MOLEX 10897041 C-Grid Breakaway Header
The MOLEX 10-89-7041 C-Grid Breakaway Header is a versatile component designed for secure and reliable connections in various electronic applications. This header offers a 2.54mm pitch, dual-row configuration, and vertical orientation, making it ideal for board-to-board and wire-to-board connections. Constructed with a copper alloy and tin plating, it ensures excellent conductivity and durability. Its breakaway design simplifies assembly and maintenance, while the high-temperature thermoplastic material allows for operation in demanding environments. The header is RoHS compliant and suitable for applications requiring a robust and space-efficient interconnect solution.
MOLEX 10897041 C-Grid Breakaway Header Specifications:
- Product Family: PCB Headers
- Series: 70280
- Application: Board-to-Board, Signal, Wire-to-Board
- Overview: C-Grid Connector Products
- Circuits (Loaded): 4
- Circuits (maximum): 4
- Color - Resin: Black
- Durability (mating cycles max): 25
- First Mate / Last Break: No
- Flammability: 94V-0
- Glow-Wire Capable: No
- Guide to Mating Part: None
- Lock to Mating Part: None
- Material - Metal: Copper Alloy
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Net Weight: 0.244/g
- Number of Rows: 2
- Orientation: Vertical
- PC Tail Length: 2.79mm
- PCB Locator: No
- PCB Retention: None
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Bag
- Pitch - Mating Interface: 2.54mm
- Plating min - Mating: 3.810µm
- Plating min - Termination: 3.810µm
- Polarized to Mating Part: No
- Polarized to PCB: No
- Shrouded: No
- Stackable: Yes
- Temperature Range - Operating: -40° to +105°C
- Termination Interface: Style: Through Hole
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V
- Duration at Max. Process Temperature (seconds): 005
- Lead-freeProcess Capability: WAVE
- Max. Cycles at Max. Process Temperature: 001
- Process Temperature max. C: 245
- Engineering Number: A-70280-0002
- Packaging Specification: PK-70873-0353-001
- Product Specification: PS-70280-001
- Sales Drawing: SDA-70280-0001-4000
