MOLEX 15246141 Mini-Fit Connector
The Mini-Fit BMI Connector is a high-current, durable, and reliable vertical header designed for board-to-board, power, and wire-to-board applications. It features a 4.20mm pitch, dual-row configuration, and is made from PA Polyamide Nylon 6/6 with UL 94V-2 flammability rating. Plated with tin for excellent corrosion resistance, it supports up to 13A per circuit at 600V, with a temperature range from -40°C to +105°C. Its robust construction ensures up to 30 mating cycles, ideal for demanding electrical installations. Compatible with snap-in plastic peg PCB lock and available in natural color for versatile usage.
MOLEX 15246141 Mini-Fit Connector Specifications:
- Pitch: 4.20mm
- Number of Circuits: 14
- Color - Resin: Natural
- Flammability: UL 94V-2
- Material - Resin: PA Polyamide Nylon 6/6
- Material - Plating Mating: Tin
- Max. Current per Circuit: 13A
- Max. Voltage: 600V
- Operating Temperature Range: -40°C to +105°C
- Durability (Mating Cycles): Up to 30 cycles
- Dimensions: Length approximately 30mm (based on series specifications)
- Pin/Contact Material: Brass
- Surface Plating - Termination: Tin
- Locking Mechanism: Snap-in Plastic Peg PCB Lock
- Termination Style: Through Hole
- PCB Thickness Compatibility: 1.80mm
Buy the Molex Series Mini-Fit BMI: 0015246141
Purchase the Molex Mini-Fit Connector series 0015246141 online today for reliable power and signal connections. Designed with a 4.20mm pitch and dual-row configuration, this high-current vertical header withstands up to 13A per circuit at 600V. Crafted from durable PA Polyamide Nylon 6/6 with tin plating, it features a snap-in plastic peg PCB lock for secure attachment. Operating efficiently from -40°C to +105°C, supporting up to 30 mating cycles, it is an ideal choice for demanding electrical and electronic systems seeking durability and performance.
Get Molex 0015246141 today—built for high-current applications and long-lasting durability in electronic assembly.
Frequently Asked Questions
Where can I buy MOLEX 15246141?
You can click on the BUY or RFQ button to purchase 15246141 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 15246141?
You can download the 15246141 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 15246141?
MOLEX
