MOLEX 1722981106 Vertical Header Connector
The MOLEX 172298-1106 is an Ultra-Fit™ Vertical Header, part of the Ultra-Fit Power Connectors series. This connector is designed for robust wire-to-board connections, offering a 6.50mm pitch and a dual-row configuration with 6 circuits. It boasts a tin (Sn) plating for reliable contact and is glow wire capable, suitable for various industrial applications. The connector's robust design and reliable performance make it ideal for power transmission in diverse electronic systems.
MOLEX 1722981106 Vertical Header Connector Specifications:
- overview: Ultra-Fit™ Power Connectors
- description: Ultra-Fit™ Vertical Header, 6.50mm Pitch, Dual Row, 6 Circuits, with Kinked Pins, Tin (Sn) Plating, Black, Glow Wire Capable
- pitch_mating_interface: 3.50mm
- pitch_termination_interface: 3.50mm
- circuits_loaded: 6
- circuits_maximum: 6
- color_resin: Black
- durability_mating_cycles_max: 25
- first_mate_last_break: No
- flammability: 94V-0
- glow_wire_compliant: Yes
- material_metal: Copper Alloy
- material_plating_mating: Tin over Nickel
- material_plating_termination: Tin over Nickel
- material_resin: Liquid Crystal Polymer
- number_of_rows: 2
- orientation: Vertical
- pc_tail_length: 3.20mm
- pcb_locator: Yes
- pcb_retention: Yes
- pcb_thickness_recommended: 1.60mm
- packaging_type: Tray
- plating_min_mating: 1.524µm
- plating_min_termination: 1.524µm
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- current_maximum_per_contact: 12.0A
- voltage_maximum: 400V AC (RMS)/DC
- temperature_range_operating: -40°C to +120°C
- termination_interface_style: Through Hole - Kinked Pin
- material_info_reach_svhc: Not Contained Per - ED/21/2016 (20 June 2016)
- halogen_free_status: Low-Halogen
- max_process_temperature_c: 260
- max_cycles_at_max_process_temperature: 002
- duration_at_max_process_temperature_seconds: 090
