MOLEX 2059570871 Micro-Lock Plus PCB Header
The Micro-Lock Plus Wire-to-Board Connector System is a 1.25mm pitch, single-row PCB header designed for reliable surface mount connections in electronic devices. Featuring a positive lock mechanism, tin-bismuth plating, and potting capability, it supports up to 8 circuits with a maximum current of 3.6A per contact and an operating temperature range of -40°C to +105°C. It is RoHS and halogen-free compliant, ensuring eco-friendly performance, and is suitable for high-density, vibration-resistant electronic assemblies. Ideal for industrial, consumer, and communication applications requiring secure and durable connectivity.
MOLEX 2059570871 Micro-Lock Plus PCB Header Specifications:
- Pitch: 1.25mm
- Number of Circuits: 8
- Maximum Circuits (Loaded): 8
- Color: Black
- Material - Metal: Brass
- Material - Plating Mating & Termination: Tin-Bismuth
- Material - Resin: Polyamide
- Operating Temperature Range: -40°C to +105°C
- Current per Contact: 3.6A
- Voltage Maximum: 50V AC/DC
- Durability (Mating Cycles Max): 30
- Surface Mount Compatibility: Yes
- RoHS & Halogen-Free: Yes
- Packaging: Embossed Tape on Reel
- Wire Range: Compatible with wire sizes supporting 8 circuits
- Guide to Mating Part: Micro-Lock Plus Receptacle Housing
- Polarity: Polarized to Mating Part and PCB
- RoHS Compliance: Yes
Buy the Molex Series Micro-Lock Plus PCB Header: 2059570871
Purchase the Molex Micro-Lock Plus PCB Header online and ensure secure, durable connections for your electronic projects. Designed with a 1.25mm pitch, it supports 8 circuits with maximum 3.6A per contact and features a positive lock mechanism for vibration resistance. Its tin-bismuth plating offers excellent corrosion resistance, and the surface-mount design facilitates easy assembly. RoHS and halogen-free compliance make it eco-friendly. Ideal for industrial, communication, and consumer electronics, this connector guarantees reliable performance in demanding environments, simplifying your manufacturing process.
Get Molex 2059570871 today—built for reliable, compact, and vibration-resistant electronic connections.
Frequently Asked Questions
Where can I buy MOLEX 2059570871?
You can click on the BUY or RFQ button to purchase 2059570871 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2059570871?
You can download the 2059570871 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2059570871?
MOLEX
