MOLEX 2147501101 Micro-Fit 3.0 Cable Assembly
The MOLEX 214750-1101 is a Micro-Fit 3.0 female-to-female cable assembly designed for reliable power and signal transmission in various applications. This assembly features a 150mm cable length, 10 circuits, and tin plating for enhanced conductivity and corrosion resistance. It is suitable for wire-to-board and wire-to-wire connections, commonly found in industrial equipment, automotive systems, and consumer electronics.
Authorized Distributors
Source:Mouser Electronics
Part No:214750-1101
Stock:731
Inv Date:05-30-2026
Price: Unit price: $5.45
Buy/RFQ:
Source:RS Americas, Inc
Part No:214750-1101
Stock:0
Inv Date:05-29-2026
Price: Unit price: $5.76
Buy/RFQ:
MOLEX 2147501101 Micro-Fit 3.0 Cable Assembly Specifications:
- overview: Micro-Fit Connector System
- application: Power, Wire-to-Board, Wire-to-Wire Assembly
- configuration: Dual Ended
- connectors: Connector to Connector Micro-Fit 3.0 Both Ends
- cable_length: 150.00mm
- circuits_loaded: 10
- color: Black
- gender: Female-Female
- lock_to_mating_part: Yes
- material_metal: Phosphor Bronze
- material_plating_mating: Tin (Sn)
- material_plating_termination: Tin (Sn)
- material_resin: Nylon
- net_weight: 21.953/g
- number_of_rows: 1
- pitch_mating_interface: 3.00mm
- plating_min_mating: 1.016µm
- plating_min_termination: 1.016µm
- single_ended: No
- wire_insulation_diameter_max: 1.85mm
- wire_size_awg: 18
- wire_cable_type: Discrete Wire, UL 10002
- current_maximum_per_contact: 8.5A
- upc: 193264585021
- elv: Not Relevant
- rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Not Low-Halogen
- mates_with: Micro-Fit 3.0 Plug Housings, Micro-Fit TPA Plug Housing, Micro-Fit 3.0 Headers
- drawing_number: 2147501101-000
