MOLEX 2153222023 Mini-Fit Jr. Cable Assembly
The MOLEX 215322-2023 is a Mini-Fit Jr. male-to-male cable assembly designed for wire-to-wire power applications. It boasts a black nylon resin housing, gold plating on the mating interface, and tin plating on the termination interface. This assembly is ideal for connecting power supplies to various devices and equipment, ensuring reliable and efficient power transmission. It is RoHS compliant and features a single row design with a 4.20mm mating interface pitch.
MOLEX 2153222023 Mini-Fit Jr. Cable Assembly Specifications:
- series: 215322
- application: Power, Wire-to-Wire
- configuration: Dual Ended
- connectors: Connector to Connector Mini-Fit Jr. Both Ends
- cable_length: 600.00mm
- circuits_loaded: 2
- color_resin: Black
- material_metal: Brass
- plating_mating: Gold (Au)
- plating_termination: Tin
- material_resin: Nylon
- net_weight: 29.280/g
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 4.20mm
- plating_min_mating: 0.762µm
- plating_min_termination: 2.032µm
- single_ended: No
- termination_interface_style: Crimp or Compression
- wire_insulation_diameter: 1.80-3.10mm
- wire_size_awg: 16
- wire_cable_type: UL 1015
- current_max_per_contact: 9.0A
- voltage_max: 600V
- upc: 193264597413
- material_info: Not Low-Halogen
- reach_svhc: Not Contained
- mates_with: Mini-Fit Jr. Receptacle Housing 5557, Mini-Fit TPA2 Cable Assembly 145135
- sales_drawing: 2153222021-000
