MOLEX 2153282022 Mini-Fit Power Cable Assembly
This Mini-Fit Jr. male-to-pigtail off-the-shelf cable assembly features a dual-row configuration with a length of 300mm, gold-plated contacts, and a black resin body. Designed for power applications, it supports a maximum current of 9.0A and voltage of 600V. The assembly uses crimp or compression termination methods with wire sizes from 16 AWG, and it offers reliable, secure electrical connections. Its compact design and high-quality materials make it suitable for various power distribution and industrial applications, ensuring durability and compliance with RoHS standards.
MOLEX 2153282022 Mini-Fit Power Cable Assembly Specifications:
- Cable Length: 300.00mm
- Number of Rows: 2
- Color - Resin: Black
- Gender: Male-Pigtail
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Wire Insulation Diameter: 1.80-3.10mm
- Wire Size AWG: 16
- Current - Maximum per Contact: 9.0A
- Voltage - Maximum: 600V
- Termination Interface: Style: Crimp or Compression
- Material - Resin: Nylon
- Net Weight: 15.080g
- Contact Material: Brass
- RoHS Compliance: Yes
- UL Listing: UL 1015
- Application: Power, Wire-to-Wire
- Connector Type: Mini-Fit Jr.-to-Pigtail
- Reference Number: 2153282022
Buy the Molex Series Mini-Fit Power Cable: 2153282022
Shop the Molex Series Mini-Fit Power Cable Assembly featuring a 300mm length, gold-plated contacts, dual-row configuration, and a durable black resin body. Designed for power applications, this assembly supports up to 9A and 600V, providing secure and reliable connections. Its high-quality crimp or compression termination methods suit 16 AWG wires, making it ideal for industrial and electronics projects. Compliant with RoHS standards, it ensures safety and environmental compliance. Purchase online today for dependable performance and quick delivery.
Order your Molex Series Mini-Fit Power Cable assembly 2153282022 today and ensure reliable, high-quality power connections for your industrial projects.
Frequently Asked Questions
Where can I buy MOLEX 2153282022?
You can click on the BUY or RFQ button to purchase 2153282022 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2153282022?
You can download the 2153282022 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2153282022?
MOLEX
