MOLEX 22022045 PCB Receptacle
The KK 254 PC Board Connector by Molex is a top-entry, 2.54mm pitch interconnect suitable for board-to-board signal applications. Featuring four circuits with hooks, this connector offers reliable electrical connections with tin-plated brass contacts, UL and CSA certifications, and flame-retardant nylon housing. Designed for through-hole mounting, it operates within a temperature range of -55°C to +105°C. Ideal for various electronic assemblies, it ensures secure mating and easy installation, making it suitable for both commercial and industrial uses requiring durable and high-performance connections.
MOLEX 22022045 PCB Receptacle Specifications:
- Pitch - Mating Interface: 2.54mm
- Number of Circuits: 4
- Color - Resin: Natural (White)
- Flammability: 94V-0
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Net Weight: 0.428 grams
- Orientation: Vertical
- PC Tail Length: 3.35mm
- PCB Thickness - Recommended: 1.60mm
- Temperature Range - Operating: -55°C to +105°C
- Termination Interface: Through Hole
- Current - Maximum per Contact: 2.5A
- Voltage - Maximum: 500V
Buy the Buy Molex KK 254 PC Board Connector Part Number 0022022045 Online
Purchase the Molex KK 254 PC Board Connector easily online to ensure high reliability in your projects. This top-entry connector features four circuits with tin-plated brass contacts, UL and CSA certifications, and a flame-retardant nylon housing. Designed for through-hole mounting, it offers secure mating and efficient electrical connections. Its compact 2.54mm pitch makes it ideal for space-constrained circuit boards in industrial or consumer electronics, providing ease of installation and long-lasting performance in various operating environments.
Buy Molex 22022045 now and experience unmatched reliability and performance in your electronic assemblies, with durable contacts and easy mounting.
Frequently Asked Questions
Where can I buy MOLEX 22022045?
You can click on the BUY or RFQ button to purchase 22022045 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 22022045?
You can download the 22022045 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 22022045?
MOLEX
