MOLEX 22032161 Wire-to-Board Connector
The KK 254 Wire-to-Board Header is a reliable vertical connector featuring 16 circuits, made with PA Polyamide Nylon and tin plating for durability and corrosion resistance. Suitable for board-to-board connections in various electronic applications, it supports a maximum voltage of 500V and a current of 4.0A per contact. The connector’s compact design includes a 3.43mm pitch, PCB retention features, and a temperature operating range up to 105°C. Certified by CSA and UL, it ensures compliance with RoHS and REACH standards, making it ideal for industrial and consumer electronics.
MOLEX 22032161 Wire-to-Board Connector Specifications:
- Number of Circuits: 16
- Material - Body: PA Polyamide Nylon
- Material - Plating: Tin
- Color - Resin: Natural (White)
- Pitch - Mating Interface: 2.54mm
- Voltage - Maximum: 500V
- Current - Maximum per Contact: 4.0A
- Temperature Range - Operating: -40°C to +105°C
- Durability (mating cycles max): Not specified
- Flammability: 94V-0
- Certification: CSA, UL
- Net Weight: 1.098g
- Orientation: Vertical
- PCB Thickness - Recommended: 1.60mm
- Lock to Mating Part: None
- Stackable: No
- Surface Mount Compatible (SMC): No
- Polarized to PCB: No
- Shrouded: No
- Packaging Type: Bag
- Assembly Process: Soldering, process temperature max 235°C, lead-free, maximum cycles at max temp 001
Buy the Molex 0022032161 – Reliable Wire-to-Board Connector for Industrial Applications
Secure your electronic assemblies with the Molex Wire-to-Board Connector. Featuring 16 circuits, nylon housing, and tin plating, this high-quality connector ensures reliable connections and long-term performance in industrial, commercial, and consumer electronics. Its compact 2.54mm pitch, rated for up to 500V and 4.0A per contact, supports efficient and safe electrical performance. Certified by UL and CSA, it guarantees compliance with global safety standards. Perfect for tight spaces, it offers easy installation and durability for demanding applications—order online now for fast delivery and seamless integration.
Get Molex 0022032161 today—designed for precision, high durability, and reliable board-to-board connections in demanding industrial environments.
Frequently Asked Questions
Where can I buy MOLEX 22032161?
You can click on the BUY or RFQ button to purchase 22032161 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 22032161?
You can download the 22032161 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 22032161?
MOLEX
