MOLEX 22122124 KK 254 Solid Header
The MOLEX 22-12-2124 is a KK 254 Solid Header, part of the KK Interconnect System. This right-angle header provides a robust and reliable connection for wire-to-board applications. It features a friction lock mechanism for secure mating and 12 circuits with 0.51µm gold plating, ensuring excellent signal integrity. Suitable for a variety of industrial and commercial applications, this header offers a compact design and ease of use. It is designed for through-hole termination and is compatible with various mating connectors.
MOLEX 22122124 KK 254 Solid Header Specifications:
- circuits_loaded: 12
- circuits_maximum: 12
- color_resin: Natural (White)
- durability_mating_cycles: 50
- flammability: 94V-0
- glow_wire_capable: No
- lock_to_mating_part: Yes
- material_metal: Brass
- material_plating: Gold
- material_resin: Nylon
- net_weight_g: 1.576
- number_of_rows: 1
- orientation: Right Angle
- pc_tail_length_mm: 3.58
- pcb_locator: No
- pcb_retention: None
- pcb_thickness_recommended_mm: 1.60
- packaging_type: Bag
- pitch_mating_interface_mm: 2.54
- pitch_termination_interface_mm: 2.54
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- shrouded: Partial
- stackable: Yes
- temperature_range_operating_c: See Product Specification
- termination_interface_style: Through Hole
- current_max_per_contact_a: 4.0
- voltage_max_v: 500
- lead_free_process_capability_wave_max_cycles: 001
- process_temperature_max_c: 235
- engineering_number: A-7478-12A241
