MOLEX 26602050 PCB Header Connector
The KK 396 Header from Molex is a durable, vertical PCB connector designed for reliable board-to-board and wire-to-board connections. It features 5 circuits with tin plating, a pitch of 3.96mm, and a maximum current of 7.0A per contact. Made from high-quality brass and polyester resin, it supports up to 25 mating cycles and operates within a temperature range suitable for various electronic applications. With a compact 3.56mm tail length, it is ideal for space-constrained environments, ensuring secure electrical connections in power and signal applications.
MOLEX 26602050 PCB Header Connector Specifications:
- Number of Circuits: 5
- Color - Resin: Natural China RoHS Green
- Material - Metal: Brass with Tin plating
- Material - Resin: Polyester
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 3.96mm
- Orientation: Vertical
- Termination Interface: Through Hole
- Current - Maximum per Contact: 7.0A
- Voltage - Maximum: 250V
- Temperature Range - Operating: Refer to Product Specification
- Process Temperature max: 235°C
- Durability (mating cycles max): 25
- Stackable: Yes
- Shrouded: Partial
- PCB Locator: Not Included
- Packaging Type: Bag
Buy the Buy Molex KK 396 Header Part Number 0026602050 Online
Secure your electronic projects with the Molex KK 396 Header, offering 5 circuits, customizable configurations, and a durable tin-plated design. Ideal for power and signal connections, this reliable PCB header ensures consistent performance and easy installation. Perfect for tight spaces, its vertical orientation and stackable design facilitate efficient wiring and maintenance. Whether for industrial automation, consumer electronics, or other applications, buy the Molex KK 396 Header online today to ensure your devices operate smoothly with high-quality connectivity that lasts.
Get Molex KK 396 Header today—built for reliable PCB connections in electronic devices with space-saving and high-current capabilities.
Frequently Asked Questions
Where can I buy MOLEX 26602050?
You can click on the BUY or RFQ button to purchase 26602050 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26602050?
You can download the 26602050 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26602050?
MOLEX
