MOLEX 346950100 Stac64 Power Header
The MOLEX 34695-0100 Stac64 Single Bay Vertical Power Header is a versatile connector solution for power distribution in various industrial applications. Designed with 10 circuits and polarization A, it ensures secure and reliable connections between wires and printed circuit boards. Constructed with a high copper alloy for the metal components and a high-temperature thermoplastic for the resin, this header provides durability and performance in demanding environments. Its vertical orientation and through-hole termination interface simplify integration into PCB designs, making it suitable for a wide range of electronic devices and systems.
MOLEX 346950100 Stac64 Power Header Specifications:
- product_family: PCB Headers
- series: 34695
- application: Power, Wire-to-Board
- comments: Polarization A
- overview: Stac64 Single, Multi-Pocket and Hybrid Header System
- product_literature_order_no: 987650-4561
- circuits_loaded: 10
- circuits_maximum: 10
- color_resin: Black
- durability_mating_cycles: 10
- first_mate_last_break: No
- glow_wire_capable: No
- keying_to_mating_part: None
- lock_to_mating_part: Yes
- material_metal: High Copper Alloy
- material_plating_mating: Tin
- material_plating_termination: Tin
- material_resin: High Temperature Thermoplastic
- net_weight_g: 8.552
- number_of_rows: 2
- orientation: Vertical
- pc_tail_length_mm: 3.36
- pcb_locator: Yes
- pcb_retention: None
- pcb_thickness_recommended_mm: 1.57
- packaging_type: Tray
- pitch_mating_interface_mm: 3.50, 5.25
- pitch_termination_interface_mm: 3.50, 5.25
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- shrouded: Yes
- stackable: No
- surface_mount_compatible: N/A
- temperature_range_operating_c: -40° to +100°
- termination_interface_style: Through Hole
- current_max_per_contact_a: 18.0, 30.0
- voltage_max: 500V
- duration_at_max_process_temp_seconds: 040
- lead_free_process_capability_wave_cycles: 003
- process_temperature_max_c: 260
- elv_compliant: Yes
- rohs_compliant: Yes
- china_rohs_compliant: Yes
- reach_svhc: Not Contained
- halogen_free_status: Low-Halogen
