MOLEX 353621150 Wire-to-Board Connector
The Sherlock Wire-to-Board Connector System features a 2.00mm pitch, vertical header with positive lock for secure connections. It has 11 circuits with kinked PC tails, made from flame-retardant nylon, and offers up to 30 mating cycles. Designed for reliable signal transmission, it operates within a temperature range of -40°C to +105°C. It is compliant with RoHS, UL, and CSA standards, and is suitable for applications requiring durable, high-quality wire-to-board connections in compact electronic assemblies.
MOLEX 353621150 Wire-to-Board Connector Specifications:
- Pitch: 2.00mm
- Circuits: 11
- Color - Resin: Natural
- Material - Resin: Nylon
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Durability: Up to 30 mating cycles
- Operating Temperature Range: -40°C to +105°C
- Voltage - Maximum: 125V
- Current - Maximum per Contact: 2.0A
- Flammability: 94V-0
- PC Tail Length: 3.30mm
- Mated Height: 8.50mm
- Orientation: Vertical
- PCB Thickness - Recommended: 1.60mm
- Packaging: Bag
- RoHS: Compliant
- UL and CSA certified
- Shrouded: No
- Stackable: No
- Surface Mount Compatible: No
- Polarized to Mating Part: Yes
- Temperature Range - Operating: -40°C to +105°C
- Termination Interface: Through Hole
Buy the Buy Molex Sherlock Wire-to-Board Part Number 353621150 Online
Purchase the Molex Sherlock Wire-to-Board Connector system online today for reliable, high-quality electronic connections. Featuring a 2.00mm pitch with 11 circuits, positive lock, kinked PC tails, and durable nylon construction, it provides secure and long-lasting connection solutions. Suitable for applications requiring rugged performance, it operates within a temperature range of -40°C to +105°C and meets RoHS, UL, and CSA standards. Order now to ensure your electronic assemblies are connected with precision and dependability.
Get Molex Sherlock wire-to-board connector today—designed for secure, reliable electronic connections with high durability and RoHS compliance.
Frequently Asked Questions
Where can I buy MOLEX 353621150?
You can click on the BUY or RFQ button to purchase 353621150 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 353621150?
You can download the 353621150 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 353621150?
MOLEX
