MOLEX 428206213 Power Connector
The Mini-Fit Sr. Power Connector is a 10.00mm pitch header designed for power applications, featuring a single row, right-angle orientation, and 6 circuits. It is rated for 50A per contact and 600V, with gold-over-nickel plating for reliable connections. The connector supports up to 100 mating cycles, has a PCB thickness of 1.57mm, and is made of high-temperature thermoplastic with brass contacts. It is RoHS and UL compliant, suitable for PCB mounting, and provides robust power distribution for industrial and electronic systems.
MOLEX 428206213 Power Connector Specifications:
- Pitch: 10.00mm
- Number of Circuits: 6
- Maximum Current per Contact: 50A
- Maximum Voltage: 600V
- Resistance to Mating Cycles: Up to 100
- Material - Metal: Brass
- Plating - Mating: Gold over Nickel
- Plating - Termination: Tin over Nickel
- Resin Material: High Temperature Thermoplastic
- Temperature Range - Operating: -40°C to +105°C
- Orientation: Right Angle
- PCB Thickness - Recommended: 1.57mm
- PCB Tail Length: 3.50mm
- Surface Mount Compatible: No
- Shrouded: No
- Stackable: No
- UL and RoHS Compliant
- Locking Mechanism: None
- Connector Style: Through Hole
- Color - Resin: Black
- Durability (Mating Cycles Max): 100
Buy the Molex 0428206213 – Reliable Power Connectors for Industrial Applications
Enhance your power distribution systems with this high-quality, 10mm pitch power connector. Designed for durability and high current capacity, it supports 50A per contact and 600V, ideal for industrial automation, machinery, and electronic equipment. Made with brass contacts and gold-over-nickel plating for corrosion resistance, this connector adapts to PCB mounting with a 1.57mm thickness, ensuring secure and reliable connections for demanding environments. Order now for seamless integration into your projects.
Buy Molex 0428206213 now and experience unmatched reliability and high current capacity for industrial power systems.
Frequently Asked Questions
Where can I buy MOLEX 428206213?
You can click on the BUY or RFQ button to purchase 428206213 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 428206213?
You can download the 428206213 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 428206213?
MOLEX
