MOLEX 436500221 Power Connector
The Micro-Fit 3.0 vertical header is a versatile, high-temperature thermoplastic connector featuring a 3.00mm pitch, single row, 2 circuits, with PCB press-fit and metal retention clip. Designed for power and wire-to-board applications, it offers up to 17.27mm mated height, ultra-reliable brass contacts with tin plating, and supports high mating durability of 30 cycles. Certified by CSA and UL, this shrouded, stackable connector operates effectively from -40°C to +105°C and is RoHS compliant, ensuring safety and stability in demanding electronic assemblies.
MOLEX 436500221 Power Connector Specifications:
- Pitch: 3.00mm
- Number of Circuits: 2
- Number of Rows: 1
- Mated Height: 17.27mm
- Material: Brass with tin plating
- Resin: High-Temperature Thermoplastic
- Color: Black
- Current: 8.5A per contact
- Voltage: 600V
- Operating Temperature: -40°C to +105°C
- Durability: Up to 30 mating cycles
- Flammability: 94V-0
- PCB Thickness: Recommended 1.60mm
- PCB Retention: Yes
- PCB Locator: Yes
- Shrouded: Yes
- Stackable: Yes
- Polarized to PCB: Yes
- RoHS & ELV Compliant: Yes
- Glow-Wire Capable: Yes
- Reel Packaging
- Process: Reflow Soldering (260°C for 30 sec)
Buy the Molex 436500221 – Reliable Power and Wire-to-Board Connectors for Industrial Applications
Enhance your electronic assemblies with the Molex Power Connector offering a 3.00mm pitch, press-fit PCB contacts, and superior durability. Perfect for power and wire-to-board applications, this RoHS-compliant, high-temperature thermoplastic connector supports up to 8.5A, operates in temperatures from -40°C to +105°C, and withstands 30 mating cycles. Its brass contacts with tin plating ensure excellent conductivity and corrosion resistance. The shrouded, stackable design simplifies assembly, making it ideal for demanding industrial environments. Buy online today and ensure reliable, safe connectivity for your projects.
Buy Molex 436500221 now and experience unmatched reliability and performance in power and wiring solutions for industrial applications.
Frequently Asked Questions
Where can I buy MOLEX 436500221?
You can click on the BUY or RFQ button to purchase 436500221 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 436500221?
You can download the 436500221 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 436500221?
MOLEX
