MOLEX 5023861570 Signal Connector
This is a high-reliability wire-to-board receptacle designed for secure connections in electronic systems. It features a 15 circuit count with a 1.25 mm pitch, 1.0A current capacity, and an operating temperature range from -40°C to +105°C. The connector is surface-mount compatible, with tin-plated copper alloy contacts, and offers durability for up to 30 mating cycles. RoHS compliant and halogen-free, it is suitable for various industrial and electronic applications requiring reliable and efficient PCB interconnections.
MOLEX 5023861570 Signal Connector Specifications:
- Number of Circuits: 15
- Color - Resin: Natural
- Durability (mating cycles max): 30
- Mating Interface Pitch: 1.25mm
- Termination Interface: Surface Mount
- Material - Metal: Copper Alloy
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Voltage - Maximum: 50V AC/DC
- Current - Maximum per Contact: 1.0A
- Operating Temperature Range: -40°C to +105°C
- Surface Mount Compatible: Yes
- Guide to Mating Part: Yes
- RoHS Compliant: Yes
- Halogen-Free: No
- Shielded: No
- Guide to Mating Part: Yes
- Lock to Mating Part: Yes
- Mated Height: 5.55mm
- Net Weight: Not specified
- Packaging Type: Embossed Tape on Reel
Buy the Molex 5023861570 – Reliable Signal Wire-to-Board Connector for Industrial Applications
Enhance your electronic assemblies with the Molex Signal Connector, featuring a 15-circuit capacity, a compact 1.25 mm pitch, and reliable tin-plated copper contacts. Designed for PCB applications, it offers a maximum current of 1.0A per contact and operates efficiently from -40°C to +105°C. Its surface-mount design ensures easy integration into your manufacturing process. RoHS compliant and halogen-free, this connector guarantees safety, durability, and superior electrical performance for various industrial and electronic projects. Purchase online today for quick, reliable delivery.
Order your Molex Series502386 5023861570 today and ensure your electronic projects benefit from dependable, high-quality PCB interconnection solutions.
Frequently Asked Questions
Where can I buy MOLEX 5023861570?
You can click on the BUY or RFQ button to purchase 5023861570 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5023861570?
You can download the 5023861570 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5023861570?
MOLEX
