MOLEX 5024430570 Wire-to-Board Connector
The 2.00mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle offers vertical single-row, 5-circuit connections designed for reliable wire-to-board applications. Constructed with durable materials, it features a natural color resin and tin-plated contacts that ensure excellent electrical performance and corrosion resistance. Rated for 3.0A and 250V AC/DC, it supports up to 30 mating cycles and is RoHS and ELV compliant. Its compact design includes PCB retention, a mated height of 10.90mm, and compatibility with surface-mount technology, making it ideal for various electronic assemblies requiring secure and efficient connections.
MOLEX 5024430570 Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 2.00mm
- Number of Circuits (Loaded): 5
- Number of Circuits (Maximum): 5
- Color - Resin: Natural
- Durability (Mating Cycles Max): 30
- Glow-Wire Capable: No
- Mated Height: 10.90mm
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Net Weight: 711.000mg
- Orientation: Vertical
- Operating Temperature Range: -40° to +105°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V AC/DC
- Surface Mount Compatible: Yes
- Packaging: Embossed Tape on Reel
- RoHS: Compliant
- ELV: Not Relevant
Buy the Molex Series CLIK-Mate 2.00mm Connector: 5024430570
Purchase the Molex Series CLIK-Mate wire-to-board connector with 2.00mm pitch, 5 circuits, and robust construction for reliable electrical connections. Designed for surface-mount applications, it features a natural resin color, tin-plated contacts, and supports up to 30 mating cycles. Rated for 3A and 250V AC/DC, it is RoHS and ELV compliant, ensuring safety and environmental standards are met. Its compact design facilitates easy assembly and provides secure PCB retention for various electronic devices and industrial applications.
Order your Molex Series CLIK-Mate 5024430570 today and ensure your electronic projects have reliable, high-quality wire-to-board connections.
Frequently Asked Questions
Where can I buy MOLEX 5024430570?
You can click on the BUY or RFQ button to purchase 5024430570 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5024430570?
You can download the 5024430570 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5024430570?
MOLEX
