MOLEX 5025841060 Wire-to-Board Connector
The 5025841060 is a 1.50mm pitch CLIK-Mate wire-to-board connector designed for reliable PCB connections in industrial and electronic applications. It features a single row, surface-mount, vertical orientation, and tin-plated copper alloy contacts for durability. Suitable for up to 2.0A current and 100V voltage, it supports 10 circuits with a maximum of 10 mating cycles and operates in temperatures from -40°C to +105°C. The connector is RoHS and China RoHS compliant, halogen-free, and designed for ease of assembly with embossed tape on reel packaging.
MOLEX 5025841060 Wire-to-Board Connector Specifications:
- Pitch: 1.50mm
- Circuits (Loaded): 10
- Maximum Circuits: 10
- Material: Copper Alloy
- Plating: Tin
- Color: Not specified
- Durability: Up to 10 mating cycles
- Operating Temperature Range: -40°C to +105°C
- Current Rating: 2.0A per contact
- Voltage Rating: 100V
- Termination Style: Surface Mount
- Orientation: Vertical
- Packaging: Embossed Tape on Reel
- RoHS & China RoHS compliant
- Halogen-Free: No
- Lock to Mating Part: Yes
- PCB Retention: Yes
Buy the Molex 502584 U–2013 Reliable Wire-to-Board Connector for Industrial Applications
Purchase the Molex 502584 wire-to-board connector online today for high-quality PCB connections in industrial and electronic devices. This surface mount, vertical connector with a 1.50mm pitch ensures secure engagement and robust performance. Capable of handling up to 2A and 100V, it supports 10 circuits with repeated mating cycles, making assembly and maintenance straightforward. Its tin-plated contacts and RoHS compliance guarantee durability, safety, and environmental responsibility. Ideal for reliable electrical integration in manufacturing, automation, and control systems.
Get Molex 502584 today—built for reliable PCB connections, supporting high durability and easy surface mounting in industrial equipment.
