MOLEX 5025850270 CLIK-Mate PCB Receptacle
The CLIK-Mate PCB Receptacle 5025850270 is a 1.50mm pitch, surface-mount, right-angle connector designed for wire-to-board applications. It features a single row with two circuits, tin-plated copper alloy construction, and a positive lock for secure connections. Suitable for durability up to 30 mating cycles, this connector operates within a temperature range of -40°C to +105°C. Compliant with EU RoHS and halogen-free standards, it ensures reliable performance in various electronic assemblies with a maximum current of 2A and voltage of 100V.
MOLEX 5025850270 CLIK-Mate PCB Receptacle Specifications:
- Pitch - Mating Interface: 1.50mm
- Pitch - Termination Interface: 1.50mm
- Number of Rows: 1
- Circuits: 2
- Color - Resin: Beige
- Durability (mating cycles max): 30
- Material - Metal: Copper Alloy
- Material - Plating Mating: Tin
- Lock to Mating Part: Yes
- Mated Height: Not specified
- Temperature Range - Operating: -40°C to +105°C
- Termination Interface: Style: Surface Mount
- Current - Maximum per Contact: 2A
- Voltage - Maximum: 100V
- Flammability: UL 94V-0
- RoHS Compliance: Yes
- Halogen-Free: Yes
- Agency Certification: UL
- Packaging Type: Embossed Tape on Reel
- Physical Dimensions: 6.40mm width, 2 circuits, right-angle orientation
- Guide to Mating Part: Not specified
Buy the Molex Series CLIK-Mate PCB Receptacle: 5025850270
Buy your Molex CLIK-Mate PCB Receptacle 5025850270 online today for a dependable wire-to-board connection solution. With a 1.50mm pitch, right-angle design, and two circuits, it offers secure mating with a positive lock feature. Made from durable copper alloy with tin plating, it withstands up to 30 mating cycles and operates within -40°C to +105°C. Fully compliant with EU RoHS and halogen-free standards, this connector ensures high performance and safety in all your electronic projects.
Order your Molex Series CLIK-Mate PCB Receptacle 5025850270 today and ensure reliable, secure connections in your electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 5025850270?
You can click on the BUY or RFQ button to purchase 5025850270 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5025850270?
You can download the 5025850270 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5025850270?
MOLEX
