MOLEX 5040500291 Wire-to-Board Connector
The Pico-Lock connector system offers a reliable 1.50mm pitch wire-to-board header designed for high-density applications. It features a dual-row, right-angle surface mount configuration with gold over nickel plating and a positive lock mechanism to ensure secure connections. Suitable for standard industrial wiring, it supports up to 3.5A per contact and a maximum voltage of 150V AC/DC. With a mated height of 2.00mm, the component is RoHS, EU ELV, and halogen-free compliant, delivering durability up to 30 mating cycles in demanding environments.
MOLEX 5040500291 Wire-to-Board Connector Specifications:
- Pitch: 1.50mm
- Number of Circuits: 2
- Mated Height: 2.00mm
- Current per Contact: 3.5A
- Maximum Voltage: 150V AC/DC
- Material - Metal: Copper Alloy
- Plating: Gold over Nickel
- Resin: High Temperature Thermoplastic
- Color: Black
- Durability (mating cycles maximum): 30
- Operating Temperature Range: -40°C to +105°C
- Surface Mount Compatible: Yes
- RoHS, EU ELV, Halogen-Free, Low-Halogen compliant
Buy the Molex 5040500291 – Reliable Wire-to-Board Connector for Industrial Applications
Secure your electronic projects with the Molex Pico-Lock wire-to-board connector featuring a 1.50mm pitch, dual-row design, and positive lock mechanism. This surface mount connector supports up to 3.5A per contact and 150V, making it ideal for industrial, automation, and control systems. Uniquely engineered with gold over nickel plating, it provides excellent corrosion resistance and long-term reliability. Easy to install with RoHS, EU ELV, and halogen-free compliance, this connector ensures a stable and safe connection in demanding environments. Purchase online today for fast delivery and guaranteed quality.
Buy Molex 5040500291 now and ensure secure, durable connections in your industrial electronics with our high-quality Pico-Lock system.
