MOLEX 512811494 FFC FPC Connector
The FFC-FPC connector with a 0.50mm pitch features surface-mount, right-angle, non-ZIF design with dual contact style and gold plating. It supports 14 circuits in a compact form, with a mated height of 1.20mm. Made from phosphor bronze with tin plating, it is designed for reliable electrical connections in tight spaces, supporting current up to 0.5A and voltages up to 50V. Operating within a temperature range of -20°C to +85°C, this connector is ideal for flexible flat cable applications in industrial electronics and consumer devices.
MOLEX 512811494 FFC FPC Connector Specifications:
- Pitch: 0.50mm
- Number of Circuits: 14
- Mated Height: 1.20mm
- Contact Material: Phosphor Bronze
- Plating: Gold on contacts, Tin on termination
- Current Rating: 0.5A per contact
- Voltage Rating: 50V
- Temperature Range: -20°C to +85°C
- Orientation: Right angle
- Mounting: Surface Mount
- Durability: Supports up to 20 mating cycles
- Surface Compatibility: Yes
- RoHS and REACH compliant
- Packaging: Embossed tape on reel
Buy the Molex 0512811494 – Reliable FFC/FPC Connector for Industrial Applications
Enhance your electronic assembly with the Molex FFC FPC connector, featuring a 0.50mm pitch, durable gold plating, and a compact surface-mount right-angle design. Ideal for tight spaces, it supports 14 circuits with a mated height of 1.20mm, ensuring reliable electrical contact. Made from high-quality phosphor bronze with tin and gold plating, it guarantees corrosion resistance and long-lasting performance. Suitable for flexible flat cables in industrial and consumer electronics, it operates between -20°C and +85°C, rated at 0.5A and 50V, offering excellent durability and reliability.
Buy Molex 0512811494 now and experience unmatched reliability and performance in electronic device connections.
Frequently Asked Questions
Where can I buy MOLEX 512811494?
You can click on the BUY or RFQ button to purchase 512811494 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 512811494?
You can download the 512811494 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 512811494?
MOLEX
