MOLEX 442060005 Power Connector
This product is a Mini-Fit Jr. power connector featuring a dual row, vertical header with an 11.90mm locking ramp and 8 circuits, designed for reliable wire-to-board power connections. It supports up to 13A current per circuit and operates within a temperature range of -40°C to +105°C. Made from durable nylon resin with tin-plated brass contacts, it is RoHS compliant and UL certified. The connector's through-hole termination and polarized design ensure secure attachment and proper mating, ideal for industrial power applications requiring high reliability and easy assembly.
MOLEX 442060005 Power Connector Specifications:
- Number of Circuits: 8
- Current per Circuit: 13A
- Maximum Voltage: 600V
- Operating Temperature Range: -40°C to +105°C
- Material - Contact: Brass with tin plating
- Material - Resin: Nylon
- Locking Ramp: 11.90mm
- PCB Thickness - Recommended: 1.80mm
- Pin Pitch - Mating Interface: 4.20mm
- Termination Interface: Through Hole
- Color - Resin: Natural
- Polarity: Polarized to PCB
- Certifications: UL, RoHS Compliant
- Durability (Mating Cycles Max): 30
- Surface Mount Compatible: No
- Shrouded: Fully
- Stackable: No
- Guide to Mating Part: 5557 Mini-Fit Jr. Receptacle Housing
- Packaging: Tray
Buy the Molex 442060005 – Reliable Power Connector for Industrial Applications
Enhance your industrial power systems with the Molex Power Connector. Designed for durability and efficiency, this 8-circuit vertical header supports up to 13A per circuit and withstands temperatures from -40°C to +105°C. Made from high-quality nylon resin with tin-plated brass contacts, it ensures secure, corrosion-resistant connections. Its polarized design prevents mis-mating, and the through-hole termination simplifies assembly. Ideal for industrial applications, this UL-certified connector guarantees reliable performance and long-lasting operation in demanding environments.
Buy Molex 442060005 now and experience unmatched reliability and performance in your industrial power connection systems.
Frequently Asked Questions
Where can I buy MOLEX 442060005?
You can click on the BUY or RFQ button to purchase 442060005 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 442060005?
You can download the 442060005 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 442060005?
MOLEX
