MOLEX 716612540 EBBI 50D Connector System
The MOLEX 71661-2540 is a robust EBBI 50D connector system engineered for demanding board-to-board and wire-to-board applications. With a 1.27mm pitch and 40 circuits, this right-angle connector offers a compact and efficient solution for connecting PCBs. Its features include a 2.79mm PC tail length, gold-plated mating interface, and tin-plated termination interface, ensuring excellent signal integrity and durability. The connector is designed for a maximum operating temperature of +105°C and supports a maximum current of 1.0A per contact, making it suitable for a wide range of industrial and commercial applications.
MOLEX 716612540 EBBI 50D Connector System Specifications:
- application_overview: EBBI 50D Connector System
- circuits_loaded: 40
- circuits_maximum: 40
- color_resin: Black
- durability_mating_cycles: 2000
- first_mate_last_break: No
- flammability: 94V-0
- glow_wire_capable: No
- guide_to_mating_part: Yes
- keying_to_mating_part: None
- lock_to_mating_part: None
- material_metal: Brass
- material_plating_mating: Gold
- material_plating_termination: Tin
- material_resin: High Temperature Thermoplastic
- net_weight_g: 7.694
- number_of_rows: 2
- orientation: Right Angle
- pc_tail_length: 2.79mm
- pcb_locator: Yes
- pcb_retention: Yes
- pcb_thickness_recommended: 1.60mm
- packaging_type: Tray
- pitch_mating_interface: 1.27mm
- pitch_termination_interface: 1.27mm
- plating_min_mating: 0.762µm
- plating_min_termination: 1.270µm
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- shrouded: Fully
- stackable: No
- smc_compatible: No
- temperature_range_operating: -40° to +105°C
- termination_interface_style: Through Hole
- current_maximum_per_contact: 1.0A
- voltage_maximum: 30V
- duration_at_max_process_temperature_seconds: 040
- lead_free_process_capability: SMC&WAVE
- max_cycles_at_max_process_temperature: 003
- process_temperature_max_c: 235
