MOLEX 878332420 Wire-to-Board Connector
The Milli-Grid connector system features a right-angle, shrouded header with 24 circuits, lead-free gold plating, and center polarization. It is designed for wire-to-board applications, offering durability up to 50 mating cycles, operating between -55°C and +105°C, with a maximum current of 2.0A per contact and voltage of 125V. Made from nylon with phosphor bronze contacts, it includes a tube packaging type, PCB locator, and lock features for secure connections, suitable for automotive and industrial use. The contact plating is gold and tin for reliable connectivity and corrosion resistance.
MOLEX 878332420 Wire-to-Board Connector Specifications:
- Number of Circuits: 24
- Orientation: Right Angle
- Contact Material: Phosphor Bronze
- Plating Mating: Gold
- Plating Termination: Tin
- Material - Resin: Nylon
- Operating Temperature: -55°C to +105°C
- Current per Contact: 2.0A
- Voltage Rating: 125V
- Pitch - Mating Interface: 2.16mm
- PCB Tail Length: 1.60mm
- Durability: Up to 50 mating cycles
- Packaging: Tube
- Flammability: UL 94V-0
- RoHS Compliance: Yes
- Halogen-Free: No
- Operating Environment: Automative and industrial applications
Buy the Molex 8788332420 – Reliable Connector for Industrial Applications
Enhance your industrial or automotive applications with this durable wire-to-board connector featuring 24 circuits, gold plating for corrosion resistance, and a right-angle shrouded design. Its robust nylon body, phosphor bronze contacts, and secure locking make it ideal for demanding environments. Operating from -55°C to +105°C, it supports up to 2.0A current per contact and ensures reliable performance over multiple mating cycles. Easy to install with a tube packaging style, this connector ensures your connections are secure and long-lasting. Order online today for quick delivery.
Buy Molex 8788332420 now and experience unmatched reliability and performance in industrial and automotive wire-to-board connections.
Frequently Asked Questions
Where can I buy MOLEX 878332420?
You can click on the BUY or RFQ button to purchase 878332420 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 878332420?
You can download the 878332420 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 878332420?
MOLEX
