MOLEX 878341011 C-Grid Connector
This 2.54mm pitch C-Grid connector features a dual-row, low-profile, vertical, shrouded design with 10 circuits, gold flash plating, and PCB locators. It is suitable for wire-to-board connections, made of flame-retardant nylon with tin plating on the termination, and offers a maximum current of 2.5A at 250V DC. The connector operates from -55°C to +120°C, integrates a center slot guide for easy mating, and complies with RoHS and UL certifications for safe and sustainable electronic assembly. Designed for reliable insertion and secure connection, ideal in various electronic applications requiring compact and durable headers.
MOLEX 878341011 C-Grid Connector Specifications:
- Pitch: 2.54mm
- Number of Circuits: 10
- Number of Rows: 2
- Color - Resin: Natural
- Material - Resin: Nylon
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Flammability: 94V-0
- Operating Temperature Range: -55°C to +120°C
- Current - Maximum per Contact: 2.5A
- Voltage - Maximum: 250V DC
- PCB Tail Length: 3.43mm
- Orientation: Vertical
- Guide to Mating Part: Center Slot
- Shrouded: Yes
- Stackable: No
- Packaging: Tray
- UL Certification: Yes
- RoHS Compliant: Yes
- Lead-Free: Yes
Buy the Molex Series C-Grid Signal Connector: 878341011
Purchase the Molex C-Grid Connector 878341011 online today to ensure reliable, high-quality wire-to-board connections. Designed with a low-profile, shrouded dual-row layout and gold flash plating, this connector provides excellent electrical performance and durability. Perfect for compact electronic assemblies operating in temperatures from -55°C to +120°C, it features PCB locators and a center slot guide for easy mating. RoHS compliant and UL certified, it guarantees safety, sustainability, and long-lasting connections, making it an ideal choice for various electronic applications requiring a robust and space-saving connector.
Get Molex 878341011 today—built for precision and long-lasting durability in your electronic projects.
