MOLEX 878982026 PCB Header Connector
The C-Grid / SL Header is a surface mount, breakaway, vertical PCB connector designed for board-to-board applications. It features 20 circuits with tin plating and is lead-free, ensuring compliance with RoHS standards. Suitable for various electronic assemblies, this connector offers reliable electrical performance at a maximum of 3.0A and 250V. Its durable nylon housing maintains stability across -55°C to +105°C, with a pitch of 2.54mm for mating and termination interfaces. Ideal for high-density circuit connections, the product is UL certified and designed for reflow soldering with up to three max temperature cycles.
MOLEX 878982026 PCB Header Connector Specifications:
- Number of Circuits: 20
- Material - Metal: Copper Alloy
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Net Weight: 1.074 grams
- Color - Resin: Not specified
- Flammability: UL Recognized
- Glow-Wire Capable: No
- Orientation: Vertical
- Stackable: No
- Temperature Range - Operating: -55°C to +105°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V
- Termination Interface: Reflow Process Compatible
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- UL Certification: Yes
- RoHS Compliant: Yes
- Lead-Free: Yes
- Process Temperature Max: 260°C
- Max Cycles at Max Temperature: 3
Buy the Buy Molex C-Grid Connector Part Number 878982026 Online
Purchase the Molex C-Grid Connector Part Number 878982026 online today to ensure your electronic projects benefit from high-quality, reliable connections. With 20 circuits, tin plating, lead-free construction, and UL certification, this surface mount connector guarantees safety and durability across temperatures from -55°C to +105°C. Its 2.54mm pitch makes it compatible with a wide range of board-to-board applications. Rely on Molex's proven design for your high-density and demanding electronic systems, ensuring seamless integration and consistent performance for your manufacturing needs.
Buy Molex 878982026 now and experience unmatched reliability and performance with durable lead-free design and UL certification for your electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 878982026?
You can click on the BUY or RFQ button to purchase 878982026 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 878982026?
You can download the 878982026 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 878982026?
MOLEX
