MOLEX 8R5E36E03C3003 Micro-Change M12 Receptacle
The Micro-Change M12 Receptacle is a robust, single-ended female connector with 5 poles, M12x1 and M14x1 threads, designed for industrial automation and sensor applications. Made from nickel-plated brass, it features IP67 and NEMA 6 ratings for superior sealing and durability. This straight connector has a length of 0.30 meters (11.81 inches), suitable for panel mounting, and supports operating temperatures from -20°C to +80°C. It carries a maximum current of 4.0A and a voltage of 250V AC/DC, ensuring reliable power and signal transmission in demanding environments.
MOLEX 8R5E36E03C3003 Micro-Change M12 Receptacle Specifications:
- Series: 120011
- IP Rating: IP67
- NEMA Rating: 6
- Type: Micro-Change (M12)
- Coupling Type: External Thread
- Gender: Female
- Length: 0.30 meters (11.81 inches)
- Material - Component: Nickel-plated Brass
- Mounting Thread Size: M14x1.0
- Net Weight: 22.07 g
- Orientation: Straight, Front
- Poles: 5
- Temperature Range - Operating: -20°C to +80°C
- Wire Size AWG: 22
- Wire/Cable Type: Leads, UL 1061
- Current - Maximum per Contact: 4.0A
- Voltage - Maximum: 250V AC/DC
Buy the Molex Series Micro-Change M12 Receptacle: 120011
Secure your industrial connections with the Molex Micro-Change M12 Receptacle, featuring 5 poles, IP67 sealing, nickel-plated brass construction, and 0.30m length. Ideal for automation and sensor applications, it supports up to 4.0A current and 250V voltage. Its robust design ensures high performance in harsh environments, making it suitable for a wide range of industrial automation systems. Order online today and enhance your system’s reliability and efficiency with this high-quality connector.
Buy Molex Micro-Change M12 Receptacle now and experience unmatched durability and reliable industrial connectivity for automation systems.
Frequently Asked Questions
Where can I buy MOLEX 8R5E36E03C3003?
You can click on the BUY or RFQ button to purchase 8R5E36E03C3003 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 8R5E36E03C3003?
You can download the 8R5E36E03C3003 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 8R5E36E03C3003?
MOLEX
