MOLEX 901301214 PCB Header
The C-Grid III Header is a high-quality, dual-row, vertical PCB connector with a shrouded, fully loaded design featuring 14 circuits and gold selective plating. Made from durable polyester resin with brass metal components, it offers reliable wire-to-board connections. With a 2.54mm pitch and operating temperature range of -55°C to +125°C, it supports applications requiring up to 3A per contact and 350V. Its robust construction ensures up to 100 mating cycles, suitable for signal and power connections in demanding electronic systems.
MOLEX 901301214 PCB Header Specifications:
- Number of Circuits: 14
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Gold 0.381um
- Material - Plating Termination: Tin 3.048um
- Material - Resin: Polyester
- Durability (mating cycles max): 100
- Operating Temperature Range: -55°C to +125°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 350V AC/DC
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- PC Tail Length: 2.90mm
- Packaging: Tray
- Surface Mount Compatible: No
- Shrouded Ends: Yes
- Stackable: No
- Orientation: Vertical
- Terminations: Through Hole
- RoHS Compliant: Yes
- UL and CSA Certified: Yes
Buy the Buy Molex C-Grid III Part Number 0901301214 Online
Purchase the Molex C-Grid III PCB Header online today to ensure your electronic assemblies benefit from durable, high-quality connections. With 14 circuits, gold plating, and a 2.54mm pitch, it is suitable for demanding signal and power applications. The robust design withstands up to 100 mating cycles and operates across a temperature range of -55°C to +125°C. Ideal for PCB connections where reliability, precision, and quality are critical, this connector supports wire-to-board solutions in various electronic devices. Order now for fast delivery and seamless integration.
Buy Molex 0901301214 now and experience unmatched reliability and high-density signal connections for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 901301214?
You can click on the BUY or RFQ button to purchase 901301214 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901301214?
You can download the 901301214 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901301214?
MOLEX
