MOLEX 901471110 PCB Connector
The C-Grid PCB connector is a vertical, single-row, 10-circuit board-to-board signal connector, featuring tin plating and RoHS compliance. Designed for reliable electrical connection, it supports a maximum operating temperature of -55°C to +105°C, with conductors rated at 3A and a maximum voltage of 350V. The connector is made of phosphor bronze with polyester insulation, offering a compact pitch of 2.54mm and a height of 2.90mm. Suitable for applications requiring robust mounting and precise mating, it ensures optimal performance in various electronic assemblies. Compatible with Series 90120 and 90121 mating parts, it provides durable connections with through-hole termination and PCB retention features.
MOLEX 901471110 PCB Connector Specifications:
- Number of Circuits: 10
- Color - Resin: Black
- Flammability: 94V-0
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 0.864g
- Number of Rows: 1
- Orientation: Vertical
- PC Tail Length: 2.90mm
- PCB Locator: No
- PCB Retention: Yes
- Recommended PCB Thickness: 1.60mm
- Packaging: Tube
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Plating min - Mating: Tin
- Plating min - Termination: Tin
- Polarized to PCB: Yes
- Surface Mount Compatible: No
- Temperature Range - Operating: -55°C to +105°C
- Termination Style: Through Hole
- Current - Max per Contact: 3A
- Voltage - Max: 350V
- Agency Certifications: CSA, UL
- RoHS and Reach Compliant
Buy the Molex Series 90147 PCB Receptacle: 901471110
Secure your electronic assemblies with the Molex Series 90147 PCB Connector, featuring a 10-circuit, vertical orientation, tin-plated design ideal for space-constrained applications. Engineered for durability, it supports a maximum of 3A current and 350V voltage, with a temperature range from -55°C to +105°C. Its robust construction includes phosphor bronze contacts, polyester insulation, and through-hole termination to guarantee solid connections and long-term performance. Perfectly compatible with Series 90120 and 90121 mating parts, it is the ideal choice for engineers seeking quality and reliability in PCB interconnect solutions.
Order your Molex Series 90147 PCB Receptacle 901471110 today and ensure reliable, efficient connections for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 901471110?
You can click on the BUY or RFQ button to purchase 901471110 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901471110?
You can download the 901471110 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901471110?
MOLEX
