MULTICOMP PRO 4404A20 IDC Connector
The 4404A-20 is a 20-position, two-row, 2.54mm pitch IDC male connector featuring gold-plated copper alloy contacts and high-temperature plastic insulation. Designed as a wire-to-board DIP plug, it utilizes IDC/IDT termination technology. The connector is rated for 1A and 30V, with a maximum contact resistance of 20 micro-ohms. It offers a minimum insulation resistance of 1000 megaohms and a dielectric withstand voltage of at least 500VAC for one minute. Operating temperature ranges from -40°C to 105°C. Suitable for industrial, communication, and networking applications.
MULTICOMP PRO 4404A20 IDC Connector Specifications:
- Current Rating: 1A
- Voltage Rating: 30V AC/DC
- Maximum Contact Resistance: 20mΩ
- Minimum Insulation Resistance: 1000MΩ
- Withstanding Voltage: 500V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- No. of Contacts: 20
- No. of Rows: 2
- Pitch Spacing: 2.54mm
- Connector Type: Wire to Board
- Material and Finish: Copper alloy, gold-plated, high-temperature plastic insulator
Buy the Buy multicomp IDC Plug Part Number 4404A20 Online
Order the multicomp IDC Connector 4404A20 online today and benefit from superior electrical features including gold-plated contacts, high insulation resistance, and robust construction. Designed for industrial, networking, and communication applications, this 20-position wire-to-board connector ensures secure connections and high performance. With operating temperatures from -40°C to 105°C and certification for 1A and 30V ratings, it guarantees durability and reliability for your electronic projects. Purchase now and ensure seamless integration in your designs with ease.
Buy multicomp IDC Plug 4404A20 now and experience unmatched reliability and performance for your wiring and communication needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 4404A20?
You can click on the BUY or RFQ button to purchase 4404A20 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 4404A20?
You can download the 4404A20 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 4404A20?
MULTICOMP PRO
