MULTICOMP PRO 5504F125S02A03 D-Sub Receptacle
The 5504F1-25S-02A-03 is a 25-position, 3A right-angle D-subminiature female connector with a PCB mount configuration, featuring gold-plated contacts and a high-temperature plastic insulator. It has an 8.08mm footprint with solder termination, suitable for industrial applications, offering reliable and durable connections. Made with copper alloy contacts plated in gold and tin, and a metal shell with nickel plating, this connector ensures excellent electrical performance and mechanical strength. It operates within -40°C to +85°C, compliant with RoHS standards, and supports voltage ratings up to 250V AC/DC with a contact resistance of 30mΩ max.
MULTICOMP PRO 5504F125S02A03 D-Sub Receptacle Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 30mΩ Max
- Insulation Resistance: 5,000MΩ Min
- Withstanding Voltage: 1,000V AC for One Minute
- Operating Temperature Range: -40°C to +85°C
- Material: PBT Insulation, Copper Alloy Contacts, Nickel-plated Metal Shell
- Contact Plating: Gold on Contact Area, Tin on Solder Tail
- Mechanical: #4—40UNC screw mount
- Footprint: 8.08mm
- Connector Type: D-Sub, Right Angle, PCB Mount
- Number of Positions: 25
Buy the Buy Multicomp Pro D-Sub Receptacle Part Number 5504F125S02A03 Online
Discover the high-performance 5504F1-25S-02A-03 D-Sub connector, ideal for industrial and electronics applications. With its 25-position, PCB right-angle layout, gold-plated contacts, and durable high-temperature plastic insulator, it ensures reliable electrical connections and mechanical strength. Operating from -40°C to +85°C, this RoHS-compliant connector supports up to 250V AC/DC and 3A current rating. Its compact 8.08mm footprint with solder termination makes it suitable for space-constrained environments. Purchase online today for quality connectivity and peace of mind in every application.
Buy Multicomp Pro 5504F125S02A03 now and experience reliable industrial connectivity with high-quality gold-plated contacts and a compact PCB mount design.
