MULTICOMP PRO 8LCM037S304BXX D-Sub Connector
This series of 90-degree D-Sub connectors features right-angle, standard D-sub interface with a durable metal front shell housing. Constructed with brass contacts gold flash over nickel, and a PBT and glass-fiber reinforced insulator, they include a board lock grounding bracket and screw lock for secure, reliable connections. Key specifications include a maximum contact resistance of 15 milliohms, insulation resistance of 1000 megaohms minimum, dielectric withstand voltage of 1000VAC for one minute, and an operating temperature range from -55°C to 105°C. Suitable for industrial and electronic applications, these connectors ensure durability and consistent performance.
MULTICOMP PRO 8LCM037S304BXX D-Sub Connector Specifications:
- Current Rating: 5A
- Min. Insulation Resistance: 1000 MΩ at 500V DC
- Maximum Contact Resistance: 15mΩ
- Dielectric Withstanding Voltage: 1000V AC for 1 minute
- Operating Temperature: -55°C to 105°C
- Insulator Material: PBT and glass-fiber reinforced UL 94V-0
- Contact Material: Brass with gold over nickel finish
- Shell Material: Steel with tin or zinc plating
- Dimensions: Typical length varies with model, see datasheet for precise measurements
- Mounting Style: PCB, right-angle
- Number of Positions: 37
- RoHS Compliant: Yes
Buy the Multicomp Series 8LC D-Sub Connector: 8LCM037S304BXX
Discover the high-quality Multicomp Series 8LC D-Sub Connector with 37 positions. Featuring brass contacts gold plated for optimal conductivity, a durable steel shell, and a glass-fiber reinforced insulator, these connectors are perfect for industrial and electronic applications. They provide reliable performance with a maximum contact resistance of 15mΩ, insulation resistance of 1000 megaohms, and withstand voltages up to 1000VAC for one minute. Designed for PCB mounting, their right-angle design simplifies installation and ensures long-term durability in demanding environments. Buy online today for dependable connectivity.
Order your Multicomp Series 8LC D-Sub Connector with 37 positions today and ensure reliable, secure electrical connections for your projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 8LCM037S304BXX?
You can click on the BUY or RFQ button to purchase 8LCM037S304BXX from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 8LCM037S304BXX?
You can download the 8LCM037S304BXX datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 8LCM037S304BXX?
MULTICOMP PRO
