MULTICOMP PRO GBJ1010F Silicon Bridge Rectifier
The Silicon Bridge Rectifier GBJ1010-F from Multicomp Pro is a high-reliability, cost-effective device rated for 1,000V PRV with a surge overload capacity of 200A peak. It features a compact, molded plastic design suitable for PCB mounting, with low forward voltage of 1.1V at 5A and a reverse current of only 5 pA at 25°C. Designed for single-phase half-wave applications at 60Hz, it can operate between -50°C and +150°C, making it ideal for various power rectification uses in industrial and electronic equipment. The device includes symbols molded on its body for polarity identification and is solderable per MIL-STD-202 Method 208, ensuring durability and ease of assembly.
MULTICOMP PRO GBJ1010F Silicon Bridge Rectifier Specifications:
- Maximum recurrent peak reverse voltage VeRM: 1000 V
- Maximum RMS voltage Ves: 700 V
- Maximum DC blocking voltage Voc: 1000 V
- Maximum average forward output current at 110°C: 10 A
- Peak forward surge current: 200 A for 8.3ms
- Maximum instantaneous forward voltage at 5A: 1.1 V
- Maximum reverse current at 25°C: 5 pA
- Operating junction temperature range: -50°C to +150°C
- Thermal resistance: 1.4 °C/W
- Storage temperature range: -50°C to +150°C
- Mounting position: Any
- Weight: 0.23 oz (6.6 g)
- Lead solderable per MIL-STD-202 Method 208
Buy the Buy Multicomp Silicon Bridge Rectifier Part Number GBJ1010-F Online
Purchase the Multicomp GBJ1010-F Silicon Bridge Rectifier online today. This high-quality device features a 1000V PRV rating, 10A continuous current, and a surge capacity of 200A, making it ideal for efficient power rectification in industrial, electronic, and manufacturing systems. Its molded plastic design ensures durability and ease of PCB mounting. With a wide operating temperature range of -50°C to +150°C, it guarantees reliable performance even in demanding environments. Order now for fast delivery and trusted quality.
Get Multicomp GBJ1010-F today—designed for high voltage rectification, durability, and reliable power conversion in industrial applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO GBJ1010F?
You can click on the BUY or RFQ button to purchase GBJ1010F from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part GBJ1010F?
You can download the GBJ1010F datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of GBJ1010F?
MULTICOMP PRO
