MULTICOMP PRO HC49S419430430506030ATF Crystal Oscillator
This is a high-precision crystal oscillator designed for use in various electronic timing and communication applications. It features a low profile, surface-mount design, and a wide frequency range from 10 to 30 MHz or 30 to 70 MHz depending on the model. The crystals provide excellent frequency stability, low ESR, and a robust ceramic package suitable for industrial, microcontroller, and wireless system use. The products are RoHS compliant, come taped and reeled for easy surface-mount assembly, and have stable operating temperature ranges for reliable performance in demanding environments.
MULTICOMP PRO HC49S419430430506030ATF Crystal Oscillator Specifications:
- Nominal Frequency Range: 10 to 30 MHz or 30 to 70 MHz depending on model
- Vibration Mode: Fundamental (AT) and 3rd overtone (AT)
- Frequency Tolerance at 25°C: +20, +30 or +50 ppm (options for +10 or +15 ppm)
- Temperature Stability: +30 ppm or +50 ppm
- Operating Temperature Range: -10°C to +60°C or -20°C to +70°C depending on model
- Storage Temperature Range: -20°C to +70°C or -30°C to +80°C
- Load Capacitance: 8 pF to 32 pF or series
- Equivalent Series Resistance: Based on ESR tables for each frequency
- Shunt Capacitance: 5pF maximum ($18 MHz) or 7pF maximum (>18 MHz)
- Drive Level: 200 μW maximum (<5 MHz), 100 μW maximum (>5 MHz)
- Insulation Resistance: 500 MΩ minimum at 100V DC
- Aging: +5 ppm per year
Buy the Multicomp Series Crystals: HC49S419430430506030ATF
Order the Multicomp crystal oscillator HC49S419430430506030ATF online today to ensure precise timing in your projects. With its low profile surface-mount design, wide frequency range, and stable performance, it’s ideal for microcontrollers, industrial equipment, and communication systems. Taped and reeled options make assembly easy, and RoHS compliance guarantees environmental safety. Designed for demanding environments, this crystal oscillator offers excellent frequency stability, low ESR, and a robust ceramic case, ensuring reliable operation in critical electronic applications.
Buy Multicomp crystal oscillator HC49S419430430506030ATF now and experience unmatched stability and reliability in your electronic timing applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO HC49S419430430506030ATF?
You can click on the BUY or RFQ button to purchase HC49S419430430506030ATF from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part HC49S419430430506030ATF?
You can download the HC49S419430430506030ATF datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of HC49S419430430506030ATF?
MULTICOMP PRO
