MULTICOMP PRO MC002941 RF Connector
The Straight SMA Square Flange Mount Field Plug Receptacle is a high-frequency RF connector designed for precise signal transmission. Constructed with stainless steel and Beryllium Copper, it ensures durability and reliable performance up to 26.5GHz. Featuring a square flange mount for secure installation, this connector operates within a temperature range of -65°C to +165°C. Its PTFE insulation offers excellent dielectric properties, making it suitable for demanding environments. With a maximum voltage rating of 500V and low VSWR, it provides stable connectivity for advanced RF applications.
MULTICOMP PRO MC002941 RF Connector Specifications:
- Connector Body Style: Straight Field Plug Receptacle
- Connector Mounting: Square Flange Mount
- Frequency Range: DC to 26.5GHz
- Impedance: 50Ω
- Voltage Rating: 500V Max.
- VSWR: Low across operating range
- Bodies Material: Stainless Steel per JIS SUS-303
- Centre Contact Material: Beryllium Copper per ASTM B196 UNS C17300
- Insulation: PTFE per ASTM D1457 and ASTM D1710
- Operating Temperature: -65°C to +165°C
- Max Coupling Torque: 7 to 10 in-lbs
- Dimensions: Millimetres (Inches) as specified
- Environmental: MIL-STD-348A compliance
Buy the Multicomp Series RF Connectors: Straight SMA Square Flange Mount Receptacle MC002941
Experience reliable RF connections with the multicomp MC002941 Straight SMA Square Flange Mount Receptacle. Designed for high-frequency applications up to 26.5GHz, it features durable stainless steel construction, Beryllium Copper contacts, and PTFE insulation for excellent dielectric properties. Its square flange mount ensures secure installation, while the operating temperature range of -65°C to +165°C makes it suitable for various environments. Perfect for RF systems requiring precision, stability, and long-lasting performance—order online now for fast delivery and quality assurance.
Get multicomp MC002941 today—built for high-frequency RF signal integrity and durability in demanding environments.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC002941?
You can click on the BUY or RFQ button to purchase MC002941 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC002941?
You can download the MC002941 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC002941?
MULTICOMP PRO
